16

 | English

1 609 92A 0J8 | (4.7.14)

Bosch Power Tools

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-22.

Typically the A-weighted noise levels of the product are:
Sound pressure level 105 dB(A); Sound power level
116 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:

a

h

= 6.5 m/s

2

, K <1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, 2014/30/EU,

2006/42/EC including their amendments and complies with
the following standards: EN 60745-1, EN 60745-2-22.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 04.07.2014

Assembly

Mounting the Protective Devices



Before any work on the machine itself, pull the mains
plug.



Operate the machine only with the protection guard
and the bow handle mounted.

Protection Guard for Cutting



For cutting with diamond-tipped abrasives, always use
the protection guard for cutting 6.



Provide for sufficient dust extraction when cutting
stone.

Release the clamping lever

8

. Place the protection guard

5

with the encoding key

17

 engaging into the groove on the

spindle collar until the shoulder of the protection guard is
seated against the flange of the power tool, and turn the pro-
tection guard

5

 to the requested position. Lock the clamping

lever

8

.

Cut-off Grinder

GWS 24-300

GWS 24-300 J

Article number

3 601 C64 3..

3 601 C64 8..

Rated power input

W

2 400

2 400

Output power

W

1 670

1 670

Rated speed

min

-1

5 000

5 000

Max. diameter for diamond cutting discs

mm

300

300

Cutting discs width, min.

mm

3.2

3.2

Cutting discs width, max.

mm

4.0

4.0

Thread of grinder spindle

M 14

M 14

Thread length (max.) of grinder spindle

mm

32

32

Max. cutting depth with cutting guide

mm

100

100

Reduced starting current

–



Weight according to EPTA-Procedure 01/2003

kg

10.3

10.3

Protection class

/

II

/

II

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.

Only for power tools without reduced starting current: Starting cycles generate brief voltage drops. Interference with other equipment/machines may
occur in case of unfavourable mains system conditions. Malfunctions are not to be expected for system impedances below 0,25 ohm.

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9
