25

MENU

(1) Navigation between the submenus TENS, EMS and MASSAGE.

(2) Return to (A) programme selection window or (B) main menu.

ENTER

(1) Menu selection.

(2) To confirm a selection made with UP/ DOWN, apart from channel intensity.

CH1±, CH2±, CH3±, CH4±

Setting pulse intensity.

Cycle

Setting, changing and confirming the number of cycles.

μs (microseconds)

Setting, changing and confirming pulse width of the individual cycles.

Hz (Hertz)

Setting, changing and confirming pulse frequency of the individual cycles.

 (cycle timer)

Setting, changing and confirming ON/OFF times of the individual cycles.

5. Start-up

1. Remove the battery cover from the base of the monitor by

undoing the catch.

2. Insert three AA 1.5 V alkaline batteries. Make absolutely

sure that you insert the batteries with the correct polarity as

marked.

3. Replace the battery cover carefully.

4. Attach the connecting cable to the electrodes (Fig. 1).

Note: The electrodes have a clip fastener to ensure easy

connection.

5. Insert the connecting cable connector into the socket at the

back of the device (Fig. 2).

6. Do not pull, twist or make any sharp kinks in the cables

(Fig. 3).

6. Programme overview

6.1 Basic information

The Digital TENS/EMS unit has a total 50 programmes:

• 20 TENS programmes

• 20 EMS programmes

• 10 MASSAGE programmes
With all programmes, you can set the length of application and (for each of the

four channels) pulse intensity separately.

Besides this, with TENS and EMS programmes 11-20, in order to physically

adapt the stimulation effect to the structure of the site of application, you can

also change both the pulse frequency, pulse width, ON and OFF times of the

individual cycles as well as the number of cycles.
Cycles are the different sequences making up the programmes. They automati-

cally run one after the other and increase the efficacy of stimulation on different

types of muscle fibre and combat premature muscle fatigue.
You will find the standard stimulation parameter settings and information on

placing the electrodes in the following programme charts for TENS, EMS and

MASSAGE.

Fig. 1

Fig. 2

Fig. 3
