24

With prolonged application, readjustment may be necessary due to time

adjustment processes at the site of application.

3.5 ON and OFF time

ON time describes the stimulation time of the cycle in seconds, i.e. the length

of the cycle in which pulses are delivered to the body. OFF time, on the other

hand, indicates the length of the cycle (in seconds) which is stimulation-free.

3.6 Cycle-controlled pulse parameter variation

In many cases it is necessary to cover the entirety of tissue structures at the

site of application by using several pulse parameters. With the Digital TENS/

EMS unit, this is done by the existing programmes automatically making a

cyclical pulse parameter change. This also prevents individual muscle groups

at the site of application from getting tired.

With the Digital TENS/EMS unit there are useful presettings for current para

meters. During the application, however, you do have the possibility of

changing pulse intensity at any time and, with individual programmes, you

can also alter pulse frequency beforehand in order implement the application

which is the most comfortable or promises the most success for you.

4. Unit description

4.1 Description of components

Display (main menu):

A  TENS/EMS/MASSAGE submenus

B   Frequency (Hz); ON time; pulse

width

C  Pulse intensity

D  Low battery

E  MEMORY display

F   Timer function (residual time

display); OFF time

G  Programme/cycle numbers

H  Operating status display

Keys:

a  MENU key

b  CYCLE TIMER key

c  FREQUENCY SETTING key

d  PULSE WIDTH SETTING key

e  CYCLE SETTING key

f  ON/OFF key

g

▲

 UP and

▼

 DOWN selection keys

h  ENTER key

i CH1±, CH2±, CH3±, CH4± keys

Accessories:

•  2x connection cable (with 2 separately controllable channels, recognisable

by their difference in colour)

•  8x adhesive electrodes

(45 x 45 mm)

4.2 Key functions

Every time a key is pressed, this is acknowledged by a signal tone in order to

ensure that any unintentional pressing of a key is detected. This signal tone

cannot be switched off.

ON/OFF

(1)  Hit briefly to switch on the device. If the key is held down for 10 seconds

when switching on, the unit automatically switches off again.

(2)  Press once (= pause mode) to interrupt and continue stimulation treat-

ment.

(3) Hold ON/OFF key down (approx. 3 seconds) to switch off the device.

▲

 and

▼

(1)  Select (A) treatment programme, (B) treatment time and (C) frequency,

pulse width, number of cycles, ON/OFF time.

(2)  The DOWN key

▼

is used to reduce pulse intensity for all channels during

stimulation.

B

A

C

D

F G H

E

g

a
b
c
d

e

h

i

f
