 23

en

 Operation

Warning!

The continuous­feed shredder must be com­

pletely assembled before use. Never assem­

ble the continuous­feed shredder on the base

unit. Operate the continuous­feed shredder in

the indicated operating position only.

Predetermined breaking point

Fig.

G

:

The built­in predetermined breaking point

protects the drive of the appliance. If an

overload occurs, the drive shaft of the con­

tinuous­feed shredder breaks. However, the

drive shaft can easily be replaced. A new

disc holder with drive shaft is available from

customer service.

Potato fritter disc

For grating raw potatoes for

rostis and potato fritters, for cutting

fruit and  vegetables into thick slices.

Grating: Process at setting 7.

Cutting: Process at setting 5.

Reversible shredding disc –

coarse / fine

for shredding vegetables, fruit and cheese,

except for hard cheese (e.g. Parmesan).

Processing at setting 3 or 4.

Designation on the reversible shredding

disc:

“2” for the coarse shredding side

“4” for the fine shredding side

Warning!

The reversible shredding disc is not suitable

for shredding nuts. Shred soft cheese with

the coarse side only at setting 7.

Grating disc – medium-fine

for grating raw potatoes, hard

cheese (e.g. Parmesan), cooled chocolate

and nuts.

Process at setting 7.

Warning!

The grating disc is not suitable for grating

soft cheese and cheese slices.

Grating disc coarse

for grating raw potatoes, e.g. for

potato pancakes or dumplings.

Process at setting 7.

Asian  vegetable disc

slices fruit and vegetables into fine

strips for Asian  vegetable dishes.

Process at setting 7.

Working with the continuous-feed

shredder

Fig.

H

:

■

Press the Release button and

move the swivel arm to

position

2

.

■

Insert the bowl:

Tilt the bowl forwards and then set it

down. Turn anti­clockwise until it locks

into place.

■

Press the Release button and

move the swivel arm to

position

3

.

■

Remove drive cover from the

drive of the continuous­feed shredder

(Fig.

H

-5a)

.

■

Hold disc holder at the lower end, ensur­

ing that the two tips are face up.

■

Carefully place the required slicing or

shredding disc onto the tips of the disc

holder

(Fig.

H

-6a)

.

In the case of reversible discs, ensure

that the required side is face up.

■

Grip disc holder at the upper end and

insert into the housing

(Fig.

H

-6b)

.

■

Attach the cover (note mark) and turn all

the way in a clockwise direction.

■

Place continuous­feed shredder on the

drive and rotate all the way in a clockwise

direction, as illustrated in

Fig.

H

-8

.

■

Turn rotary switch to recommended

setting.

■

Put food to be processed in the feed tube

and push down with the pusher.

Warning!

Prevent the cut ingredients from building up

in the outlet opening.

Tip:

 To ensure even cutting results, process

thin ingredients in bunches.
