22

en

Operation

Important information concerning the

use of the whisk (Figure

E

):

The whisk should almost touch the bottom

of the bowl to ensure that the ingredients

are optimally mixed. If not, adjust the height

of the whisk as follows:

■

Remove mains plug.

■

Press the Release button and

move the swivel arm to

position

2

.

■

Insert the whisk into the drive

until the whisk locks into position.

■

Hold whisk in place and loosen nut clock­

wise using open­ended wrench (size 8).

■

Set the whisk to the optimum height by

rotating the whisk:

– Turn clockwise: Raise

– Turn anti­clockwise: Lower

■

Press the Release button and

move the swivel arm to

position

1

.

■

Check the height of the whisk

and, if required, correct.

■

When the height has been set

correctly, press Release button

and move the swivel arm to

position

2

.

■

Hold whisk in place and tighten nut

anticlockwise using open­ended wrench

(size 8).

Working with the bowl and the tools

Fig.

F

:

■

Press the Release button and

move the swivel arm to

position

2

.

■

Insert the bowl:

Tilt the bowl forwards and then set it

down. Turn anti­clockwise until it locks

into place.

■

Depending on the processing task, insert

the stirrer, whisk or kneading hook until it

locks into position.

Note:

If using the kneading hook, rotate the dough

deflector until the kneading hook can lock

into position

(Fig.

F

-4b)

.

■

Put the ingredients to be processed into

the bowl.

■

Press the Release button and move the

swivel arm to position

1

.

■

Attach the cover.

■

Set the rotary switch to the desired

setting.

Our recommendation:

–

Professional flexi stirring whisk:

First mix at setting 1­2, then setting

3­5 as required

–

Professional beating whisk:

setting 7, mix in at setting 1

–

Kneading hook:

first stir in at setting 1, knead at setting 3

Adding more ingredients

■

Switch off the appliance with the rotary

switch.

■

Add more ingredients through the feed

tube in the cover.

or

■

Remove lid.

■

Press the Release button and

move the swivel arm to

position

2

.

■

Add ingredients.

After using the appliance

■

Switch off the appliance with the rotary

switch.

■

Remove mains plug.

■

Remove lid.

■

Press the Release button and

move the swivel arm to

position

2

.

■

Take the tool out of the drive.

■

Remove the bowl.

■

Clean all parts, see “Cleaning and

servicing”.

Continuous-feed shredder

W

Risk of injury

Do not grip the sharp blades or edges of the

cutting discs. Take hold of cutting discs by

the edge only. Before attaching / removing

the continuousfeed shredder, wait until the

drive has come to a standstill and pull out

the mains plug. Do not reach into the feed

tube.
