16

 | English

1 609 92A 0AN | (14.10.13)

Bosch Power Tools

The spray surface must be clean, dry and grease-free.

– Roughen smooth surfaces and then remove the sanding dust.

Suitable spray materials and recommended diluting
agents



When diluting, pay attention that the spray material
and the diluting agent correspond.

When using a faulty

diluting agent, lumps can develop that can lead to clogging
of the spray gun.

The tool is not suitable for processing dispersion paint (wall
paint/latex).

Please also observe the practical advice/tips of the spray ma-
terial manufacturers.

Diluting Spray Material

For spray material that needs to be diluted, proceed as follows:

– Take the measuring cup

21

.

– Stir the spray material thoroughly.
– Fill a sufficient quantity of spray material into the spray-

material container

8

. (see “Filling in Spray Material”,

page 16)

– Dilute the spray material by 10 % with paint thinner.

Examples:

– Stir the spray material thoroughly.
– Carry out a test-spray run on a test surface.

(see “Spraying”, page 16)

When the spraying pattern is perfect, start the spray job.

or

When the spraying result is not satisfactory or when no paint
comes out, please continue as described under “Correction of
Malfunctions” on page 18.

Filling in Spray Material (see figures C1

–

C2)



Before any work on the machine itself, pull the mains
plug.

– Unscrew the container

8

 from the spray gun.

– Turn the suction tube

10

 so that the spray material can be

sprayed with almost no residue:

– Fill the spray material into the container and screw the con-

tainer firmly to the spray gun.

Starting Operation



Observe correct mains voltage! The voltage of the pow-
er source must agree with the voltage specified on the
nameplate of the machine. Power tools marked with
230 V can also be operated with 220 V.



Pay attention that the base unit cannot draw in dust or
other contamination during operation.



Make sure never to spray on the base unit.

Switching On

To save energy, only switch the fine-spray system on when
you are using it.

– Plug the mains plug into a socket outlet.
– Grasp the spray gun by the handle and point it at the spray

surface.

– Firstly, press the On/Off switch

18

.

– Pull the trigger switch

9

 on the spray gun.

Note:

When the base unit is switched on, air always flows out

at the nozzle

11

.

Switching Off

– Release the trigger switch

9

 and press the On/Off switch

18

.

– Pull the mains plug from the socket outlet.

Working Advice

Spraying (see figures D – E)
Note:

Observe the wind direction when operating the power

tool outdoors.

– Firstly, carry out a test-spray run and adjust the spray pat-

tern and the spray material quantity according to the spray
material. (For adjustments, see the following sections)

– Be absolutely sure to hold the spray gun at a consistent dis-

tance of 5 – 15 cm perpendicular to the spray object.

– Begin the spraying procedure outside the target area.
– Move the spray gun evenly cross-wise or up-and-down, de-

pending on the spray pattern setting.
An even surface quality is achieved when the paths overlap
by 4 – 5 cm.

– Avoid interruptions within the spray surface.

Guiding the spray gun evenly will provide uniform surface
quality.

Non-uniform clearance and spray angle lead to heavy forma-
tion of paint mist and thus to an uneven surface.

– End the spraying procedure outside the target area.

Never completely empty the container for the spray material
by spraying. If the suction tube is no longer immersed in the
spray material, the spray jet will be interrupted and this will
result in an inconsistent surface.

When coating material builds up on the nozzle and air cap,
clean both parts with the corresponding solvent.

Adjusting the Spray Pattern (see figure F)



Never actuate the trigger switch 9 while adjusting the
air cap 2.

– Loosen the union nut

3

.

– Turn  the  air  cap

2

 to the requested position.

– Firmly retighten the union nut.

Spray material

Recommended
dilution

Wood stains, oils, glazes, impregna-
tions, anti-rust primers

undiluted

Water, wallpaper remover

undiluted

Solvent or water-dilutable paints, prim-
ers, radiator paint, automotive top
coats, thick-coat finishes

At least 10 %
diluted

Amount of spray material [ml]

200 300

400 500

Paint thinner [ml]

20

30

40

50

For spray jobs on horizontal
surfaces/objects

toward the

front

 in nozzle

direction

For spray jobs overhead

toward the

rear

 in handle

direction
