On/Off switch

19

Hose connection (base unit)

20

Carrying strap

21

Measuring cup

22

Air filter cover

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

Measured sound values determined according to EN 60745
and EN 50580.

Typically the A-weighted sound pressure level of the product
is 74 dB(A). Uncertainty K = 3 dB.
The noise level when working can exceed 80 dB(A).

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:
a

h

< 2,5 m/s

2

, K = 1,5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical data” is in conformity with the fol-
lowing standards or standardization documents: EN 60 335
and the directives 2011/65/EU, 2006/42/EC,
2004/108/EC including their amendments.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, ETM9,
D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 18.10.2013

Assembly



Before any work on the machine itself, pull the mains
plug.

Connecting the Air Hose (see figures A1

–

A2)

– Open  the  holding  clamp

16

 and unwind the air hose

13

completely from the base unit

15

.

Connecting to the spray gun:
– Firmly insert an SDS connector

14

 of the air hose in align-

ment with the arrow mark into the hose port of the spray
gun

6

.

– Turn the SDS connector until the lock engages.
Connecting the base unit:
– Firmly insert the second SDS connector of the air hose in

alignment with the arrow mark into the port of the base unit

19

.

– Turn the SDS connector until the lock engages.

Fastening the Carrying Strap (see figure B)

In order to reach all surfaces to be sprayed and maintain flexibil-
ity, you can sling on the base unit with the carrying strap

20

.

– Attach one strap end to each eyelet

17

.

Operation

Preparing for Operation



Spraying on the sides of water bodies (lakes, rivers,
etc.) or neighbouring surfaces in the direct catchment
area is not permitted.

When purchasing paint, varnish and spray material, pay at-
tention to their environmental compatibility.

Preparing the Spray Surface
Note:

Cover off the vicinity of the spray surface thoroughly

and generously.

The spray mist contaminates the environment. When spray-
ing in enclosures, surfaces not covered can become contami-
nated.

Fine-spray System

PFS 65

Article number

3 603 B06 1..

Rated power input

W

280

Spraying capacity

g/min

130

Atomising output

W

0 – 65

Required time for application
of paint on 5 m

2

min

10

Container capacity for spray
material

ml

600

Length of air hose

m

1.8

Weight according to
EPTA-Procedure 01/2003

kg

2.8

Protection class

/

II

The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9
