33

UA



Page 18



Operation Instructions

 Operating

Instructions

Power button

Power switch on/off.

Up (+) and Down (-) buttons

Used to adjust (increasing/decreasing)

temperature settings in 1°C/1°F (or 2°F)

increments in a range of 17°C/62°F to 30°C/86°F

(or 88°F) or the TIMER setting in a range of 0~

24hrs.

NOTE: The control is capable of displaying

temperature in degrees Fahrenheit or degrees

Celsius. To convert from one to the other, press

and hold the Up and Down buttons at the same

time for 3 seconds.

LED display
Shows the set temperature in °C or °F and the

Auto-timer settings. While on DRY and FAN

modes, it shows the room temperature.

Shows Error codes and protection code:

E1-Room temperature sensor error.

E2-Evaporator temperature sensor error.

E3-Condenser temperature sensor error (on some

      models).

E4-Display panel communication error.

EC-Refrigerant leakage detection malfunction(on

      some models).

E7-Zero-crossing malfunction.

P1-Bottom tray is full--Connect the drain hose and

      drain the collected water away.If protection

      repeats, call for service.

Note: When one of the above malfunctions occurs, turn

off the unit, and check for any obstructions. Restart the

unit, if the malfunction is still present, turn off the unit

and unplug the power cord. Contact the manufacturer

or its service agents or a similar qualified person for

service.

COOL operation

· Press the "MODE" button until the "COOL" indicator

light comes on.

· Press the ADJUST buttons "+" or "-" to select your

desired room temperature. The temperature can be

set within a range of 17°C~30°C/62°F~88°F(or 86°F).

· Press the "FAN SPEED" button to choose the fanspeed.

HEAT operation(cooling only models without)

· Press the  "MODE" button until the  "HEAT" indicator

light comes on.

· Press the  ADJUST buttons "+" or " - " to select your

desired room temperature. The temperature can be

set within a range of 17°C~30°C/62°F~88°F (or 86°F).

· Press the "FAN SPEED" button to choose the fan

speed.

Note: For some models, the fan speed can not be

adjusted under HEAT mode.

DRY operation

· Press the  "MODE" button until the  "DRY" indicator

light comes on.

· Under this mode, you cannot select a fan speed or

adjust the temperature. The fan motor operates at

LOW speed.

· Keep windows and doors closed for the best

dehumidifying effect.

· Do not put the duct to window.

AUTO operation

· When you set the air conditioner in AUTO mode, it

will automatically select cooling, heating(cooling

only models without), or fan only operation

depending on what temperature you have selected

and the room temperature.

· The air conditioner will control room temperature

automatically round the temperature point set by you.

· Under AUTO mode, you can not select the fan speed.

NOTE: Under AUTO mode, both the AUTO mode and

the actual operation mode indicator lights illuminate

for some models.

FAN operation

· Press the  "MODE" button until the"FAN " indicator

light comes on.

· Press the "FAN SPEED" button to choose the fan

speed. The temperature can not be adjusted.

· Do not put the duct to window.

TIMER operation

· When the unit is on, press the Timer button will

initiate the Auto-off stop program, the TIMER OFF

indicator light illuminates. Press the UP or down

button to select the desired time. Press the TIMER

button again within 5 seconds, the Auto-on start

program is initiated.  And the  TIMER ON indicator

 Кнопки «Вгору» (+) і «Вниз» (-)

Використовується для регулювання (збільшення/зменшення) тем-

ператури з кроком в 1 °C в діапазоні від 17 °C до 30 °C або встанов-

лення ТАЙМЕРА в діапазоні від 0 до 24 годин.

ПРИМІТКА. На панелі керування відображається температура в

градусах Фаренгейта або в градусах Цельсія. Для переходу від

одних одиниць вимірювання до інших одночасно натисніть і утри-

муйте кнопки «+» і «-» протягом 3 секунд.



Page 18



Operation Instructions

 Operating

Instructions

Power button

Power switch on/off.

Up (+) and Down (-) buttons

Used to adjust (increasing/decreasing)

temperature settings in 1°C/1°F (or 2°F)

increments in a range of 17°C/62°F to 30°C/86°F

(or 88°F) or the TIMER setting in a range of 0~

24hrs.

NOTE: The control is capable of displaying

temperature in degrees Fahrenheit or degrees

Celsius. To convert from one to the other, press

and hold the Up and Down buttons at the same

time for 3 seconds.

LED display
Shows the set temperature in °C or °F and the

Auto-timer settings. While on DRY and FAN

modes, it shows the room temperature.

Shows Error codes and protection code:

E1-Room temperature sensor error.

E2-Evaporator temperature sensor error.

E3-Condenser temperature sensor error (on some

      models).

E4-Display panel communication error.

EC-Refrigerant leakage detection malfunction(on

      some models).

E7-Zero-crossing malfunction.

P1-Bottom tray is full--Connect the drain hose and

      drain the collected water away.If protection

      repeats, call for service.

Note: When one of the above malfunctions occurs, turn

off the unit, and check for any obstructions. Restart the

unit, if the malfunction is still present, turn off the unit

and unplug the power cord. Contact the manufacturer

or its service agents or a similar qualified person for

service.

COOL operation

· Press the "MODE" button until the "COOL" indicator

light comes on.

· Press the ADJUST buttons "+" or "-" to select your

desired room temperature. The temperature can be

set within a range of 17°C~30°C/62°F~88°F(or 86°F).

· Press the "FAN SPEED" button to choose the fanspeed.

HEAT operation(cooling only models without)

· Press the  "MODE" button until the  "HEAT" indicator

light comes on.

· Press the  ADJUST buttons "+" or " - " to select your

desired room temperature. The temperature can be

set within a range of 17°C~30°C/62°F~88°F (or 86°F).

· Press the "FAN SPEED" button to choose the fan

speed.

Note: For some models, the fan speed can not be

adjusted under HEAT mode.

DRY operation

· Press the  "MODE" button until the  "DRY" indicator

light comes on.

· Under this mode, you cannot select a fan speed or

adjust the temperature. The fan motor operates at

LOW speed.

· Keep windows and doors closed for the best

dehumidifying effect.

· Do not put the duct to window.

AUTO operation

· When you set the air conditioner in AUTO mode, it

will automatically select cooling, heating(cooling

only models without), or fan only operation

depending on what temperature you have selected

and the room temperature.

· The air conditioner will control room temperature

automatically round the temperature point set by you.

· Under AUTO mode, you can not select the fan speed.

NOTE: Under AUTO mode, both the AUTO mode and

the actual operation mode indicator lights illuminate

for some models.

FAN operation

· Press the  "MODE" button until the"FAN " indicator

light comes on.

· Press the "FAN SPEED" button to choose the fan

speed. The temperature can not be adjusted.

· Do not put the duct to window.

TIMER operation

· When the unit is on, press the Timer button will

initiate the Auto-off stop program, the TIMER OFF

indicator light illuminates. Press the UP or down

button to select the desired time. Press the TIMER

button again within 5 seconds, the Auto-on start

program is initiated.  And the  TIMER ON indicator

 Кнопка живлення

Використовується для ввімкнення/вимкнення живлення.

 Світлодіодний дисплей

Показує встановлену температуру в °C або °F та налаштування

таймера. У режимах ОСУШЕННЯ та ВЕНТИЛЯЦІЯ він показує темпе-

ратуру в приміщенні.

Коди помилок, що відображаються на дисплеї:

E1-Помилка датчика температури в приміщенні.

E2-Помилка датчика температури випарника.

E3-Помилка датчика температури конденсатора (у деяких моде-

лях).

E4-Помилка зв’язку з панеллю дисплея.

EC-Витік холодоагенту (у деяких моделях).

E7-Помилка переходу через нуль.

P1-Піддон заповнений - Підключіть зливний шланг і злийте зібрану

воду. Якщо помилка не зникає, зверніться в авторизований сервіс-

ний центр.

ПРИМІТКА. При виникненні однієї з перерахованих вище несправ-

ностей вимкніть пристрій і перевірте наявність перешкод. Переза-

пустіть пристрій, якщо несправність не зникла, вимкніть пристрій і

від’єднайте кабель живлення. Зверніться до виробника, кваліфіко-

ваного фахівця або в авторизований сервісний центр для вирішен-

ня проблеми.
