20

 | English

1 609 92A 0B3 | (30.4.14)

Bosch Power Tools

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for routing grooves, edges, profiles
and elongated holes as well as for copy routing in wood, plas-
tic and light building materials, while resting firmly on the
workpiece.
With reduced speed and with appropriate routing bits, non-
ferrous alloys can also be machined.

The light of this power tool is intended to illuminate the power
tool’s direct area of working operation and is not suitable for
household room illumination.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Routing motor

2

Plunge base

3

Non-plunge base

4

Handle (insulated gripping surface)

5

Adjustment knob for fine adjustment of depth-of-cut
(plunge base)

6

Scale for depth-of-cut fine adjustment

7

Release lever for plunge action

8

Index mark for fine adjustment

9

Scale for depth-of-cut adjustment (plunge base)

10

Slide with index mark (plunge base)

11

Depth stop (plunge base)

12

Turret stop

13

Base plate

14

Guide plate

15

Thumbwheel for speed preselection

16

Knurled screw for depth stop (plunge base)

17

Tightening nut with collet

18

Router bit *

19

Lock-on button for On/Off switch

20

On/Off switch

21

Securing latch for removal of motor

22

Clamping lever for plunge base/non-plunge base

23

Seat for parallel guide rods

24

Adjustment knob for depth-of-cut fine adjustment (non-
plunge base)

25

Clamping lever for depth-of-cut coarse adjustment (non-
plunge base)

26

Coarse adjustment notches for non-plunge base

27

Spindle lock button

28

Open-end spanner, size 24 mm

29

Knurled screw for extraction adapter (2x) *

30

Extraction adapter (plunge base) *

31

Extraction hose (Ø 35 mm) *

32

Extraction adapter (non-plunge base) *

33

Intermediate ring for extraction adapter (non-plunge
base) *

34

Scale for depth-of-cut adjustment
(non-plunge base)

35

Parallel guide *

36

Guide rod for parallel guide (2x) *

37

Wing bolt for fine adjustment of parallel guide (2x) *

38

Wing bolt for coarse adjustment of
parallel guide (2x) *

39

Fine-adjustment knob for parallel guide*

40

Adjustable edge guide for parallel guide *

41

Wing bolt for guide rods of parallel guide (2x) *

42

Router compass/guide-rail adapter *

43

Router compass handle *

44

Wing bolt for coarse adjustment of
router compass (2x) *

45

Wing bolt for fine adjustment of
router compass (1x) *

46

Fine-adjustment knob for router compass *

47

Centring screw for compass stop *

48

Base spacer
(included in the “router compass” set) *

49

Guide rail *

50

SDS guide-bushing adapter

51

Fastening screw for guide bushing adapter (2x)

52

Release lever for guide bushing adapter

53

Guide bushing

54

Fastening screw for guide plate

55

Centring pin

56

Fastening screws for non-plunge base *

57

Specialty Allen key for depth-of-cut fine adjustment
(non-plunge base) *

58

Extension for depth-of-cut fine adjustment
(non-plunge base) *

59

Extraction hood for edge routing *

60

Fastening screw for extraction hood *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
