 English |

21

Bosch Power Tools

F 016 L81 142 | (7.12.16)

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-13.

Typically the A-weighted noise levels of the product are:
Sound pressure level 95 dB(A); sound power level
103 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-13:
a

h

= 6.0 m/s

2

, K = 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Assembly

For Your Safety



Warning! Switch off, remove plug from mains before
adjusting cleaning or if the cable is cut, damaged or en-
tangled.



Caution! Do not touch the rotating chain.



Do not operate the chain saw near other people, chil-
dren or animals. Do not operate the chain saw after
drinking alcohol or under the influence of intoxicating
drugs or medication.

Electrical Safety

Your power tool is double insulated for safety and requires no
earth connection. The operating voltage is 230 V AC, 50 Hz
(for non-EU countries 220 V, 240 V as applicable). Only use
approved extension cables. Contact your Bosch Service Cen-
tre for details.

Only extension cables of design type H07 RN-F or IEC
(60245 IEC 66) are permitted for use.

When operating the chain saw with an extension cable, the
following conductor cross-sections are required:
– 1.0 mm

2

: max. length 40 m

– 1.5  mm

2

: max. length 60 m

– 2.5  mm

2

: max. length 100 m

It is recommended for increased electrical safety to use a Re-
sidual Current Device (RCD) with a tripping current of not
more than 30 mA. Always check your RCD every time you use
it.

Chain saw

AKE 30-19 S

AKE 35-19 S

AKE 40-19 S

Article number

3 600 H36 D..

3 600 H36 E..

3 600 H36 F..

Rated power input

W

1 900

1 900

1 900

Chain speed (no-load)

m/s

12

12

12

Blade length

cm

30

35

40

Chain type

3/8" – 90

3/8" – 90

3/8" – 90

Drive link thickness

mm

1.1 (0.043")

1.1 (0.043")

1.1 (0.043")

Amount of drive links

45

52

57

Oil reservoir capacity

ml

200

200

200

Automatic chain oiler







Toolless chain tensioning (SDS)







Nose sprocket

–





Kickback brake







Run down brake







Metal gripping teeth







Weight according to EPTA-Procedure 01:2014

kg

4.3

4.4

4.5

Protection class

/

II

/

II

/

II

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.

Starting cycles generate brief voltage drops. Interference with other equipment/machines may occur in case of unfavourable mains system conditions.
Malfunctions are not to be expected for system impedances below 0.25 ohm.
