Operating various settings for this unit (Setup menu)

English

INTR

ODUCTION

AD
DITIONAL

INFORMA

T

ION

APPENDIX

PRE

PARA

T

ION

BA
S

IC

OPERA

T

ION

AD
VANCED

OPERA

T

ION

Extra Speaker Assignment

Selects the application for the EXTRA SP (SP1/SP2)
terminals.

Notes

•

When setting “Extra Speaker Assignment” to “Zone2” or “Presence”, surround
back channel signals for main unit are separately output from other channels.

•

When setting “Extra Speaker Assignment” to “Zone2 + Zone3”, surround and
surround back channel signals for main unit are separately output from other
channels.

LFE / Bass Out

Selects speaker(s) for outputting low-frequency
components of the LFE (low-frequency effect sound)
channel or other channels. The output status is as follows.

LFE channel signals

Low-frequency components of other channel signals

Front Speaker

Sets the sizes of front left and right speakers.

Note

•

If “LFE / Bass Out” is set to “Front”, “Front Speaker” automatically
switches to “Large” even when it is set to “Small”.

Center Speaker

Sets the size of center speaker.

Surround Speaker

Sets sizes of left and right surround speakers.

y

•

When “None” is selected, the sound field programs automatically enter
the Virtual CINEMA DSP mode.

Surround Back Speaker

Sets sizes of left and right surround back speakers.

Choices:

Zone2*, Zone2 + Zone3, Presence, None

Zone2

Assigns the SP1 terminals for Zone2 speakers
and disables the SP2 terminals.

Zone2 +
Zone3

Assigns the SP1 terminals for Zone2 speakers
and SP2 terminals for Zone3 speakers.

Presence

Assigns the SP1 terminals for presence
speakers and disables the SP2 terminals.

None

Disables the EXTRA SP (SP1/SP2)
terminals.

Choices:

Subwoofer, Front, Both*

Parameter

Subwoofer

Front

speakers

Other

speakers

Subwoofer

Output

Not output

Not output

Front

Not output

Output

Not output

Both

Output

Not output

Not output

Parameter

Subwoofer

Front

speakers

Other

speakers

Subwoofer

[1]

[2]

[2]

Front

Not output

[3]

[2]

Both

[3]

[4]

[2]

[1]

Outputs low-frequency components of the channel of speaker,

the size of which is set to “Small”.

[2]

Outputs low-frequency components when the sizes of speakers

are set to “Large”.

[3]

Outputs low-frequency components of the front left and right

channels and the channel of speaker, the size of which is set to

“Small”.

[4]

Outputs low-frequency components of the front left and right

channels.

Choices:

Small, Large*

Small

Select this when small speakers are
connected. Low-frequency components of the
front left and right channels are output from a
subwoofer.

Large

Select this when large speakers are
connected.

Choices:

None, Small*, Large

None

Select this when no center speaker is
connected. Center channel signals are spread
to front left and right speakers.

Small

Select this when a small center speaker is
connected. Low-frequency components of
center channel are output from a subwoofer.
If a subwoofer is not connected they are
output from front speakers.

Large

Select this when a large center speaker is
connected.

Choices:

None, Small*, Large

None

Select this when no surround speakers are
connected. Surround channel signals are
spread to front left and right speakers.
“Surround Back Speaker” automatically
switches to “None” when this is selected.

Small

Select this when small surround speakers are
connected. Low-frequency components of
surround channels are output from a
subwoofer. If a subwoofer is not connected
they are output from front speakers.

Large

Select this when large surround speakers are
connected.

Choices:

None, Large x 1, Small x 1, Large x 2, Small x 2*

None

Select this when no surround back speaker
are connected. Surround back channel signals
are output from the surround L/R speakers
and subwoofer. If the subwoofer is disabled,
they are output from the surround L/R
speakers and front speakers.

Large x 1

Select this when one large surround back
speaker is connected.

Small x 1

Select this when one small surround back
speaker is connected.

Large x 2

Select this when two large surround back
speakers are connected.

Small x 2

Select this when two small surround back
speakers are connected.
