11

 En

Connections

English

INTR

ODUCTION

AD
DITIONAL

INFORMA

T

ION

APPENDIX

PRE

PARA

T

ION

BA
S

IC

OPERA

T

ION

AD
VANCED

OPERA

T

ION

■

Presence left and right speakers (PL and PR)

The presence speakers supplement the sound from the
front speakers with extra ambient effects produced by the
sound field programs (page 27). We recommend that you
use the presence speakers especially for the CINEMA
DSP sound field programs. To use the presence speakers,
connect the speakers to SP1 terminals and then set “Extra
Speaker Assignment” to “Presence” (page 49).

Connect your speakers to the respective terminals according to your speaker layout. The following illustration shows how
to connect speakers for 7.1-channel speaker layout.

y

•

You can connect Zone2/3 speakers to the EXTRA SP (SP1/SP2) terminals (page 59).

•

You can connect up to two subwoofers. When two subwoofers are connected, the same sound is output from them.

FR

PR

PL

C

FL

0.5 to 1 m (1 to 3 ft)

0.5 to 1 m (1 to 3 ft)

1.8 m

(6 ft)

1.8 m

(6 ft)

1/4 from

bottom

Connecting speakers

a

b

c

d

e

f

g

h

i

j

k

SUBWOOFER

SPEAKERS

FRONT

CENTER

SINGLE

CLASS 2 WIRING

CABLAGE

CLASSE 2

SURROUND

SURROUND BACK/

BI-AMP

ZONE2/PRESENCE

1

2

SP1

NETWORK

SUR.BACK

SUBWOOFER

H INPUT

AUDIO

OUT

ZONE3

OUT

ZONE2

OUT

FRONT

SURROUND

SUR. BACK

PRE OUT

CENTER

SINGLE

3

HDMI 4

CENTER

E

c

g

f

h

i

e

d

b

a

k

j

Speakers

Jacks on this unit

7.1-channel

6.1-channel

5.1-channel

a

Front left

FRONT (L)

✔

✔

✔

b

Front right

FRONT (R)

✔

✔

✔

c

Center

CENTER

✔

✔

✔

d

Surround left

SURROUND (L)

✔

✔

✔

e

Surround right

SURROUND (R)

✔

✔

✔

f

Surround back left

(Surround back for 6.1-channel)

SURROUND BACK (L)
(SINGLE)

✔

✔

g

Surround back right

SURROUND BACK (R)

✔

h

Subwoofer 1

SUBWOOFER 1

✔

✔

✔

i

Subwoofer 2

SUBWOOFER 2

Option

Option

Option

j

Presence left

SP1 (L)

Option

Option

Option

k

Presence right

SP1 (R)

Option

Option

Option
