22

FM/AM TUNING

You can use the automatic preset tuning method to
automatically store FM stations. This function enables this
unit to automatically tune into FM stations with strong
signals and store up to 40 (8 stations in each of the 5
groups, A1 to E8) of those received stations in order. You
can then easily recall any preset stations by selecting the
preset station numbers where they are stored.

• Any station data stored under a preset station number is cleared

when you store a new station under that preset station number.

• If the number of received stations does not reach 40 (E8),

automatic preset tuning automatically stops once searching all
available stations are tuned into and stored.

• Only FM stations with sufficient signal strength are stored

automatically by automatic preset tuning. If the station you
want to store is weak in signal strength, try using the manual
preset tuning method.

1

Rotate the INPUT selector (or press TUNER
on the remote control) to select TUNER.

2

Press FM/AM on the front panel to select FM
as the reception band.

FM appears in the front panel display.

3

Press and hold MEMORY on the front panel
for more than 3 seconds.

The preset station group and the MEMORY and
AUTO indicators flash in the front panel display.

4

Press TUNING

l

 /

h

 once to begin

automatic preset tuning.

Press

h

 to tune into higher frequencies.

Press

l

 to tune into lower frequencies.

When automatic preset tuning is complete, the
frequency of the last preset station is shown in the
front panel display.

• If TUNING

l

 /

h

 is not pressed within approximately 5

seconds while the MEMORY and AUTO indicators are
flashing, automatic preset tuning automatically begins from the
currently displayed frequency and proceeds toward higher
frequencies.

• Received stations are sequentially programmed to 8 stations in

each preset station group. If 8 stations are all programmed in a
preset station group, another 8 stations are sequentially
programmed in the next preset station group.

Automatic preset tuning

Notes

ON/OFF

INPUT

MAIN ZONE

PHONES

BASS

MASTER

ON

OFF

MD/TAPE MONITOR

PURE DIRECT

5

5

1

0

1

4

4

2

2

3

3

+

–

VOLUME

l

 TUNING

h

ZONE 2 ON/OFF

ZONE CONTROL

FM/AM

EDIT

A/B/C/D/E

1

2

3

4

5

6

7

8

MEMORY

MAN'L/AUTO FM

TUNING MODE

AUTO/MAN'L

TREBLE

5

5

1

0

1

4

4

2

2

3

3

+

–

BALANCE

5

5

1

0

1

4

4

2

2

3

3

R

L

LOUDNESS

5

7

1

FLAT

6

4

8

2

10

–30dB

3

9

SPEAKERS

B

A

2

1

3 4

0

12

12

2

8

4

∞

20

20

60

60

26

26

40

40

16

16

-dB

-dB

INPUT

TUNER

or

Front panel

Remote control

Notes

FM/AM

MEMORY

MAN'L/AUTO FM

l

 TUNING

h
