 English |

9

Bosch Power Tools

1 609 92A 0NL | (14.5.14)



Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools.

Such preventive safety measures reduce the risk of

starting the power tool accidentally.



Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool.

Power

tools are dangerous in the hands of untrained users.



Maintain power tools. Check for misalignment or bind-
ing of moving parts, breakage of parts and any other
condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use.

Many accidents are caused by poorly maintained power
tools.



Keep cutting tools sharp and clean.

Properly maintained

cutting tools with sharp cutting edges are less likely to bind
and are easier to control.



Use the power tool, accessories and tool bits etc. in ac-
cordance with these instructions, taking into account
the working conditions and the work to be performed.

Use of the power tool for operations different from those
intended could result in a hazardous situation.

Service



Have your power tool serviced by a qualified repair per-
son using only identical replacement parts.

This will en-

sure that the safety of the power tool is maintained.

Safety Warnings for Drills



Use auxiliary handle(s), if supplied with the tool.

Loss

of control can cause personal injury.



Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord.

Cutting ac-

cessory contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the operator an
electric shock.



Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance.

Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.



Switch off the power tool immediately when the tool in-
sert jams. Be prepared for high reaction torque that
can cause kickback.

The tool insert jams when:

— the power tool is subject to overload or
— it becomes wedged in the workpiece.



Hold the machine with a firm grip.

High reaction torque

can briefly occur while driving in and loosening screws.



Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.



Always wait until the machine has come to a complete
stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.

Products sold in GB only

: Your product is fitted with a

BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.

Products sold in AUS and NZ only

: Use a residual current de-

vice (RCD) with a rated residual current of 30 mA or less.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for drilling in wood, metal, ceramic
and plastic, especially at hard to reach locations. Machines
with electronic speed control and right/left rotation are also
suitable for screwdriving and thread tapping.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Rotational direction switch

2

Thumbwheel for speed preselection

3

Chuck key

4

On/Off switch

5

Key type drill chuck

6

Insulated handle

Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.

Technical Data

Angle Drill

GWB 10 RE

Article number

0 601 132 7..

Rated power input

W

400

No-load speed

min

-1

0 – 1 300

Rated speed

min

-1

0 – 750

Rated torque

Nm

2.2

Chuck clamping range

mm

10

The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
