Safety warnings specific for wire brushing operations

f

Be aware that wire bristles are thrown by the brush

even during ordinary operation. Do not overstress the

wires by applying excessive load to the brush.

The wire

bristles can easily penetrate light clothing and/or skin.

f

If the use of a guard is recommended for wire brushing,

do not allow any interference of the wire wheel or

brush with the guard.

Wire wheel or brush may expand in

diameter due to work load and centrifugal forces.

Additional safety warnings

Wear safety goggles.

f

Use suitable detectors to determine if utility lines are

hidden in the work area or call the local utility company

for assistance.

Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-

sion. Penetrating a water line causes property damage or

may cause an electric shock.

f

Release the On/Off switch and set it to the off position

when the power supply is interrupted, e. g., in case of a

power failure or when the mains plug is pulled.

This pre-

vents uncontrolled restarting.

f

Do not touch grinding and cutting discs before they

have cooled down.

The discs can become very hot while

working.

f

Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.

Products sold in GB only

: Your product is fitted with an

BS 1363/A approved electric plug with internal fuse (ASTA

approved to BS 1362).

If the plug is not suitable for your socket outlets, it should be

cut off and an appropriate plug fitted in its place by an author-

ised customer service agent. The replacement plug should

have the same fuse rating as the original plug.

The severed plug must be disposed of to avoid a possible

shock hazard and should never be inserted into a mains sock-

et elsewhere.

Products sold in AUS and NZ only

: Use a residual current de-

vice (RCD) with a rated residual current of 30 mA or less.

Product Description and Specifica-

tions

Read all safety warnings and all instruc-

tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire

and/or serious injury.

While reading the operating instructions, unfold the graphics

page for the machine and leave it open.

Intended Use

The machine is intended for cutting, roughing and brushing of

metal and stone materials without the use of water.

For cutting with bonded abrasives, a special cutting guide (ac-

cessory) must be used.

When cutting in stone, provide for sufficient dust extraction.

With approved sanding tools, the machine can be used for

sanding with sanding discs.

Product Features

The numbering of the product features refers to the illustra-

tion of the machine on the graphics page.

1

Spindle lock button

2

On/Off switch

3

Auxiliary handle (insulated gripping surface)

4

Grinder spindle

5

Protection guard for grinding

6

Locking screw for protection guard

7

Mounting flange with O-ring

8

Grinding disc *

9

Clamping nut

10

Two-pin spanner for clamping nut *

11

Quick-clamping nut

*

12

Carbide grinding head *

13

Protection guard for cutting *

14

Cutting disc *

15

Protection guard for for grinding cup *

16

Grinding cup *

17

Two-pin spanner, offset, for grinding cup *

18

Hand guard *

19

Spacer discs *

20

Rubber sanding plate *

21

Sanding sheet *

22

Round nut *

23

Cup brush *

24

Cutting guide with dust extraction protection guard *

25

Diamond cutting disc *

26

Handle (insulated gripping surface)

* Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Noise/Vibration Information

Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:

Sound pressure level 93 dB(A); Sound power level

104 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:

Surface grinding: a

h

= 8.5 m/s

2

, K = 1.5 m/s

2

,

Disk sanding: a

h

= 3.5 m/s

2

, K = 1.5 m/s

2

.
