32

 | English

To

restart

 the tool, set the on/off switch

(6)

 to the off posi-

tion and then switch the power tool on again.

Impact shutdown

The integrated impact shutdown switches the power tool off
as soon as it hits the floor. The status indicator

(41)

 then

flashes red. To

restart

 the tool, set the on/off switch

(6)

 to

the off position and then switch the power tool on again.

User interface (see figure F)

(GWS 18V-10 SC / GWS 18V-10 PSC)

The user interface

(5)

 is used to preselect the speed and to

indicate the status of the power tool.

Run-out brake

The power tool is fitted with the electronic
Bosch Brake System. When it is switched off,
the abrasive tool is brought to a complete stop
within a few seconds. This means that the run-
out time is significantly shorter than for angle

grinders without a run-out brake and enables the power tool
to be set down sooner.

Speed preselection

(GWS 18V-10 SC / GWS 18V-10 PSC)

You can use the button for speed preselection

(40)

 to preselect the required speed, even during operation. The information in

the table below describes the recommended values.

Material

Application

Application tool Speed

preselection
level

GWS 18V-10 SC

(100/115/
125 mm)

[min

-1

]

GWS 18V-10 SC

(150 mm)

[min

-1

]

GWS 18V-10
PSC

(125 mm)

[min

-1

]

Metal

Removing paint

Sanding sheet

1

4500

4500

4500

Metal

Brushing, remov-
ing rust

Cup brush, abras-
ive disc

1

4500

4500

4500

Stainless
steel

Grinding

Grinding disc/
fibre disc

2

6000

6000

6000

Metal

Rough grinding

Grinding disc

3

Max.

Max.

Max.

Metal

Cutting

Cutting disc

3

Max.

Max.

Max.

Stone

Cutting

Diamond cutting
disc

3

Max.

Max.

Max.

The values specified for speed levels are guide values.

u

The rated speed of the accessory must be at least
equal to the maximum speed marked on the power
tool.

 Accessories running faster than their rated speed

can break and fly apart.

Rechargeable battery

Bosch

 sells some cordless power tools without a re-

chargeable battery. You can tell whether a rechargeable bat-
tery is included with the power tool by looking at the pack-
aging.

Charging the battery

u

Use only the chargers listed in the technical data.

 Only

these chargers are matched to the lithium-ion battery of
your power tool.

Note:

Lithium-ion rechargeable batteries are supplied par-

tially charged according to international transport regula-
tions. To ensure full rechargeable battery capacity, fully
charge the rechargeable battery before using your tool for
the first time.

Inserting the Battery

Push the charged battery into the battery holder until it
clicks into place.

Removing the Battery

To remove the rechargeable battery, press the battery re-
lease button and pull the battery out.

Do not use force to do

this.

The rechargeable battery has two locking levels to prevent
the battery from falling out if the battery release button is
pressed unintentionally. The rechargeable battery is held in
place by a spring when fitted in the power tool.

Battery charge indicator

The green LEDs on the battery charge indicator indicate the
state of charge of the battery. For safety reasons, it is only
possible to check the state of charge when the power tool is
not in operation.
