28

 | English

An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.

u

Only use the battery with products from the manufac-
turer.

 This is the only way in which you can protect the

battery against dangerous overload.

Protect the battery against heat, e.g. against
continuous intense sunlight, fire, dirt, water
and moisture.

 There is a risk of explosion and

short-circuiting.

u

Caution! When using the power tool with

Bluetooth

®

,

a

fault may occur in other devices and systems, aero-
planes and medical devices (e.g. pacemakers, hearing
aids). Also, damage to people and animals in the im-
mediate vicinity cannot be completely excluded. Do
not use the power tool with

Bluetooth

®

in the vicinity of

medical devices, petrol stations, chemical plants,
areas with a potentially explosive atmosphere or in
blasting areas. Do not use the power tool with

Bluetooth

®

in aircraft. Avoid using the product near

your body for extended periods.

The

Bluetooth

®

word mark and logos are registered trade-

marks owned by Bluetooth SIG, Inc. and any use of such
marks by Robert Bosch Power Tools GmbH is under li-
cense.

Product Description and
Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.

Please observe the illustrations at the beginning of this oper-
ating manual.

Intended use

The power tool is intended for cutting and brushing metal,
stone, plastic and composite materials, roughing metal,
plastic and composite materials as well as making holes in
stone materials using diamond annular cutters, without the
use of water. Make sure that the correct protective guard is
used (see "Operation", page 36).
Sufficient dust extraction must be provided when cutting
stone.
With approved abrasive tools, the power tool can be used for
sanding with sanding discs.
The power tool must not be used to grind stone materials
with diamond grinding heads.

(GWS 18V-10 SC / GWS 18V-10 PSC)

With the

Bluetooth

®

 Low Energy Module

GCY 42

 inserted,

power tool data and settings can be transferred between the
power tool and a mobile device by means of

Bluetooth

®

 wire-

less technology.

Product Features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

Unlocking lever for protective guard

(2)

Direction of rotation arrow on housing

(3)

Spindle lock button

(4)

LED work light

(5)

User interface

(GWS 18V-10 SC / GWS 18V-10 PSC)

(6)

On/off switch

(GWS 18V-10 / GWS 18V-10 SC)

(7)

Cover for

Bluetooth

® module

(GWS 18V-10 SC / GWS 18V-10 PC /
GWS 18V-10 PSC)

(8)

Rechargeable battery

a)

(9)

Rechargeable battery release button

a)

(10)

Vibration-damping auxiliary handle (insulated grip-
ping surface)

(GWS 18V-10 SC / GWS 18V-10 PC /
GWS 18V-10 PSC)

(11)

Standard auxiliary handle (insulated gripping sur-
face)

(GWS 18V-10)

(12)

On/off switch

(GWS 18V-10 PC / GWS 18V-10 PSC)

(13)

Unlocking lever for on/off switch

(GWS 18V-10 PC / GWS 18V-10 PSC)

(14)

Extraction guard for grinding

a)

(15)

Protective guard for grinding

(16)

Protective guard for cutting

a)

(17)

Cover for cutting

(18)

Mounting flange with O‑ring

(19)

Carbide grinding head

a)

(20)

Grinding disc

a)

(21)

Disc brush (dia. 22.22 mm)

a)

(22)

Disc brush (M14)

a)

(23)

Cutting disc

a)

(24)

Diamond cutting disc

a)

(25)

Quick-clamping nut with bar

(26)

Handle (insulated gripping surface)

(27)

Grinding spindle

(28)

Hand guard

a)

(29)

Extraction guard for cutting with cutting guides

a)

(30)

Rubber sanding pad

a)

(31)

Abrasive disc

a)

(32)

Round nut

a)

(33)

Two-pin spanner for clamping nut/round nut

(34)

Cup brush

a)

(35)

Conical brush

a)

(36)

Diamond annular cutter

a)
