 English |

17

Bosch Power Tools

1 609 92A 0L0 | (16.5.14)

Assembly

Inserting/Replacing the Batteries

Alkali-manganese batteries are recommended for the
measuring tool.

To open the battery lid

6

, press on the latch

7

 and fold the

battery lid up. Insert the batteries. When inserting, pay
attention to the correct polarity according to the repre-
sentation on the inside of the battery compartment.

When the battery indication

8

 flashes, the batteries are

weak. When the battery indication flashes for the first time,
the measuring tool can still be operated for approx. 2 h.

When the battery indication

8

 lights up constantly, meas-

uring is no longer possible. The measuring tool automati-
cally switches off after a short time.

Always replace all batteries at the same time. Only use
batteries from one brand and with the identical capacity.



Remove the batteries from the measuring tool
when not using it for extended periods.

When stor-

ing for extended periods, the batteries can corrode
and self-discharge.

Operation

Initial Operation



Protect the measuring tool against moisture and
direct sun light.



Do not subject the measuring tool to extreme tem-
peratures or variations in temperature.

As an exam-

ple, do not leave it in vehicles for a long time. In case of
large variations in temperature, allow the measuring
tool to adjust to the ambient temperature before put-
ting it into operation. In case of extreme temperatures

or variations in temperature, the accuracy of the meas-
uring tool can be impaired.



Avoid hard knocks to the measuring tool or drop-
ping it.

Damaging the measuring tool can cause accu-

racy to be compromised. Following a hard knock or
fall, carry out a check by comparing the laser lines or
plumb beams with a known horizontal or vertical refer-
ence line or verified perpendicular points.

Switching On and Off

To

switch on

 the measuring tool, press the On/Off button

3

 once briefly. Immediately after the switching on, the

measuring tool projects the three laser lines 0 °, 45 ° and
90 ° from the exit openings

1

. Furthermore, the battery

indication

8

 lights up for 3 s.



Do not point the laser beam at persons or animals
and do not look into the laser beam yourself, not
even from a large distance.

When the On/Off button

3

 is pressed a second time, the

measuring tool switches over from 3-line operation to
2-line operation: Only the 0 ° and the 90 ° laser lines are
projected.

To

switch off

 the measuring tool, press the On/Off button

3

 a third time.

Deactivating the Automatic Shut-off

The measuring tool switches off automatically after an
operating duration of 30 minutes.

To deactivate the automatic switch-off, press the On/Off
button

3

 for 3 s when you switch on the measuring tool.

When the automatic switch-off is deactivated, the laser
lines flash briefly to confirm after the switching on.



Do not leave the switched-on measuring tool unat-
tended and switch the measuring tool off after use.

Other persons could be blinded by the laser beam.

Dimensions

156 x 102 x 98 mm

Degree of protection

IP 54 (dust and splash water protected)

Tile laser

GTL 3

Professional

1) The working range can be decreased by unfavourable environmental conditions (e. g. direct sun irradiation).

2) The angular accuracy between the 45 ° laser line and the 90 ° laser line is max. ± 0.4 mm/m.

The measuring tool can be clearly identified with the serial number

5

 on the type plate.
