Operation

Starting

f

The blade continues to rotate for a few sec-
onds after the machine is switched off. Al-
low the motor/blade to stop rotating before
switching “on” again.

f

Do not rapidly switch off and on.

Note:

To aid starting push handle down to lift

front wheels.

Starting (see figure E)

n

Press and hold the safety button

2

.

o

Squeeze the switch lever

1

 towards

the handle.
Release the safety button

2

.

Note:

There is a short delay in the motor starting

after engaging the switch lever

1

.

Stopping

Release the switch lever

1

.

The machine is fitted with a blade brake. This
safety feature stops the blade from rotating in a
few seconds.

Mowing (see figures G

–

H)

Place the garden product on the edge of the
lawn, as close to the power point as possible.
Work away from the power point.
Position the cable to opposite side (already
done) at the end of each turn.
The grass combs

8

 allow a very close cut to the

wall or edge. Beware of running combs

8

 into

objects while cutting close to walls/edges.
When mowing

do not allow the motor to la-

bour.

The motor is protected by a safety cut out which
is activated when the blades become jammed,
clogged or if the motor is overloaded. When this
occurs, stop using the machine.

The safety cut out will only reset if the switch le-
ver

1

 is released.

Remove the plug from the power supply, clear
any obstruction and wait a minute for the safety
cut out to reset before continuing to use the ma-
chine.

f

Always wear gardening gloves when han-
dling or working near the sharp blades.

Note:

When waiting for a reset, operating switch

lever

1

 too early with the machine plugged into

the supply will prolong the reset time of the
safety cut out.
If the garden product cuts out again, increase
the height of cut or postpone use until condi-
tions improve. Please refer to “trouble shooting
table”.
