WARNING:

 For your safety, it is required that

the plug attached to the machine is connected
with the extension cord. The coupling of the ex-
tension cord must be protected against splash
water, be made of rubber or coated with rubber.
The extension cord must be used with a cable
strain relief.
The connection lead must be inspected for signs
of damage at regular intervals and may only be
used if in perfect conditions.
If the supply cord is damaged, it must be re-
placed by a Bosch Service Centre.

Products sold in GB only

: Your product is fitted

with an BS 1363/A approved electric plug with
internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets,
it should be cut off and an appropriate plug fit-
ted in its place by an authorised customer serv-
ice agent. The replacement plug should have the
same fuse rating as the original plug.
The severed plug must be disposed of to avoid a
possible shock hazard and should never be in-
serted into a mains socket elsewhere.

Products sold in AUS and NZ only

: Use a resid-

ual current device (RCD) with a rated residual
current of 30 mA or less.

Assembly

f

Ensure the cables are not trapped when
folding/unfolding top/bottom handles. Do
not drop the handles.

Handle assembly (see figure A)

Note:

The handle top

3

 is height adjustable. Fix

handles in desired position

I

 or

II

.

Attach cable to cable restraint

11

 ensuring that

sufficient cable slack is available. (non GB mod-
els) (see figure B)

Note:

Ensure that the cable clip supplied is used

to fix the cable to the handle.

Snap together the grassbox (see figure C)

Snap the grassbox top on the grassbox bottom
by pushing all the “snap fits” together around
the edges starting at rear and working towards
the front.

Grassbox fitting/removing (see figure D)

Lift the deflector guard

5

 and hold up, fit or re-

move the grassbox

10

.

For non grass collection the mower can be used
without the grassbox

10

 in position, with the de-

flector guard

5

 in the down position.

Adjusting the Cutting Height (see figure F)

f

Stop, release switch lever and wait until the
motor stops before adjusting height.

The

blades continue to rotate after the machine
is switched off, a rotating blade can cause in-
jury.

f

Caution  –  do not touch the rotating blade.

For the first cutting of the season, a high cutting
height should be selected.
Your garden product has 3 settings that result to
the following cutting heights:

Remove the grassbox

10

 to aid adjustment.

Make sure that all wheels

9

 are set to the same

cutting height.

n o

Insert the handle bottom

6

 into the holes

provided and secure with the screws.

p

Attach the handle top

3

 with the bolts and

wing nuts

4

 to the handle bottom

6

.

I

20 mm

II

40 mm

III

60 mm

n

Lift the garden product and pull/push the
wheel

9

 to the front of the garden product

using the hand position on the wheel.

o

Raise/lower the wheel

9

.

p

Allow wheel

9

 to locate in desired posi-

tion.
