the box. Make sure that all items listed in the packing
list are included.

Q

Inspect the tool carefully to make sure no breakage
or damage occurred during shipping.

Q

Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
tool.

Q

If any parts are damaged or missing do not operate
this product until the parts are replaced.

WARNING:

If any parts are damaged or missing do not
operate this product until the parts are replaced.
Failure to heed this warning could result in
serious personal injury.

WARNING:

Do not attempt to modify this product or create
accessories not recommended for use with this
product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.

WARNING:

To prevent accidental starting that could cause
serious personal injury, always disconnect the
engine spark plug wire from the spark plug pack
when assembling parts.

INSTALLING THE POWER HEAD SHAFT TO THE
ATTACHMENT

See Figure 2.

WARNING:

Never install, remove, or adjust any attachment
while power head is running. Failure to stop the
engine can cause serious personal injury.

The attachment connects to the power head shaft by
means of a coupler device.

Q

Loosen the knob on the coupler of the power head
shaft and remove the end cap from the attachment.

Q

Push in the button located on the attachment shaft.
Align the button with the guide recess on the power
head coupler and slide the two shafts together.
Rotate the attachment shaft until the button locks into
the positioning hole.

NOTE:

If the button does not release completely in the

positioning hole, the shafts are not locked into place.
Slightly rotate from side to side until the button is locked
into place.

Q

Tighten the knob securely.

WARNING:

Be certain the knob is fully tightened before

o p e r a t i n g   e q u i p m e n t ;   c h e c k   i t   p e r i o d i c a l l y   f o r
tightness during use to avoid serious personal injury.

REMOVING THE ATTACHMENT FROM THE POWER
HEAD

For removing or changing the attachment:

Q

Loosen the knob.

Q

Push in the button and twist the shafts to remove and
separate ends.

ATTACHING THE HANGER CAP

See Figure 3.
There are two ways to hang your attachment for storage.

Q

To use the hanger cap, push in the button and place
the hanger cap over end of the lower end attachment
shaft. Slightly rotate the cap from side to side until the
button locks into place.

Q

The secondary hole in the attachment shaft can be
used for hanging purposes as well.

ATTACHING THE FRONT HANDLE

See Figure 4.

RBC430SES

Q

Install the front handle onto the top side of the drive
shaft boom with the barrier bar on the same side as
the recoil starter (compare to product images in figure
sheet or on giftbox)

Q

Reinstall the clamp, align the screw to the screw hole
on the front handle.

Q

Tighten bolts securely.

RBC430SBS
NOTE:

The throttle trigger must be mounted to the

operator’s right side.

Q

Remove the clamp (Item 28),

Q

Place the handle in the bracket (Item 30) located on
the shaft housing.

Q

Hold the stamping clamp and align the bolts into the
bracket.

Q

Adjust the handle bar for best operator control in a
comfortable upright position.

Q

Tighten bolts with the stamping wrench to hold the
bike handle securely.

ATTACHING THE GRASS DEFLECTOR

See Figure 5.

Q

Attach the blade guard to the mounting bracket
and align the screw holes on the blade guard to the
screws on the mounting bracket.

Q

Using the combination wrench, tighten all two screws
securely.

NOTE:

 When using the string head, the grass deflector

must be attached to the blade guard.

Q

Attach the grass deflector to the blade guard and
