WARNING:
The operation of any power tool can result in
foreign objects being thrown into your eyes,
which can result in severe eye damage. Before
beginning power tool operation, always wear
s a f e t y g o g g l e s o r s a f e t y g l a s s e s w i t h s i d e
shields and, when needed, a full face shield. We
recommend Wide Vision Safety Mask for use
over eyeglasses or standard safety glasses with
side shields. Always use eye protection which is
marked to comply with EN 166.
SAVE THESE INSTRUCTIONS
INTRODUCTION
This product has many features for making its use
more pleasant and enjoyable. Safety, performance, and
dependability have been given top priority in the design
of this product making it easy to maintain and operate.
DESCRIPTION OF FIGURES
RBC430SES
Figure 1
1. Shoulder strap
2. Tri-arc Blade
3. Drive shaft
4. Coupler
5. Strap hanger
6. Ignition switch
7. Trigger lock
8. Rear handle
9. Primer bulb
10. Fuel cap
11. Recoil starter
12. Throttle trigger
13. Latch
14. Foam tube
15. Front handle
15 b. Barrier
16. Wing knob
17. Blade deflector
18. Choke lever
19. Grass deflector
20. Cutting line
21. Reel easy
TM
string head
22.Pro cut
TM
string head
Figure 2
23. Lock button
24. Guide recess
25. Power head (upper) shaft
26. Position hole
Figure 3
27. Hole on the attachment hanger to fit lock button of
lower booms
28. Hole on lower attachment
29. Attachment hanger
Figure 4
30. Screw
31. Clamp
Figure 5
32. Gear case assembly
33. Mounting bracket
34. Holding pin tool
35. Stamping, wrench, combination
36. Reel easy string head
37. Bolt
Figure 10
38. Trimmer line cut-off blade
Figure 12
39. Start position
40. Run position
Figure 18
41. Tri-arc Blade protector
Figure 15
42. Idle speed screw
Figure 21
43. Filter screen
44. Air filter cover
Figure 17
45. Oil cap/dipstick
46. Hatched area
47. Oil fill hole
48. Funnel
Figure 13
49. Drive shaft
50. Retainer
Figure 20
51. Top cover
52. Screw
53. Spark play
Figure 19
54. Cover
55. Latches
56. Bump/Feed knob
