18

5) Keep the engine level, and feed new oil up to the edge of the oil refill port.

In refill, use a lubricant refill container.

6) After refill, securely tighten the oil gauge. Insufficient tightening of the oil

gauge will lead to oil leakage.

POINTS ON OIL

– Never discard replaced engine oil in garbage, earth or sewage ditch. Disposal of oil is regulated by law. In disposal, always follow the

relevant laws and regulations. For any points remaining unknown, contact Authorized Service Agent.

– Oil will deteriorate even when it is kept unused. Perform inspection and replacement at regular intervals (replace with new oil every 6

months).

CLEANING OF AIR CLEANER

DANGER: INFLAMMABLES STRICTLY PROHIBITED

Interval of Cleaning and Inspection: Daily (every 10 operating hours)

– Turn the choke lever to the full close side, and keep the carburetor off

from dust or dirt.

– Remove the air cleaner cover-fixing bolts.

– Pull the cover lower side and detach the air cleaner cover.

– If oil adheres to the element (sponge), squeeze it firmly.

– For heavy contamination:

1) Remove the element (sponge), immerse it in warm water or in water-

diluted neutral detergent, and dry it completely.

2) Clean the element (felt) with gasoline, and dry it completely.

– Before attaching the element, be sure to dry it completely. Insufficient

drying of the element may lead to difficult startup.

– Wipe out with waste cloth, oil adhering around the air cleaner cover and

plate breather.

– Immediately after cleaning is finished, attach the cleaner cover and

tighten it with fixing bolts. (In remounting, first place the upper claw, and
then the lower claw.)

Points in Handling Air Cleaner Element

– Clean the element several times a day, if excessive dust adheres to it.

– If operation continues with the element remaining not cleared of oil, oil in

the air cleaner may fall outside, resulting in oil contamination.

CHECKING THE SPARK PLUG

– Only use the supplied universal wrench to remove or to install the spark plug.

– The gap between the two electrodes of the spark plug should be 0.7-0.8mm

(0.028"-0.032").  If the gap is too wide or too narrow, adjust it.  If the spark
plug is clogged with carton or fouled, clean it thoroubhly or replace it.

CAUTION : Never touch the spark plug connector while the engine is running

(danger of high voltage electric shock).

 Plate

 Fixing bolt

 Air cleaner cover

 Element (sponge)

 Breather Part

 Element (felt)

 Pick this part and remove the element (felt).

0.7 mm - 0.8 mm

(0.028”-0.032”)
