GB

44

GT 4030

Storage

■

Inspect all bolts for tightness.

■

Inspect the electrical contacts of the appli-
ance for corrosion, clean with a fine wire
brush if necessary and then spray with a con-
tact spray.

8.1

Changing the spool (10)

Replacement spool: GT 4030 Art. No. 113349.

Precondition:

 The appliance must be switched off

and the rechargeable battery removed from the
appliance.

Inserting and removing the spool

1. Take the replacement spool out of holder

(01/6).

2. Press (10/a) the two unlock buttons (10/1) at

the same time and remove cover (10/5).

3. Remove empty spool (10/2).

4. Insert (10/b) a new spool (10/4). Ensure that

spring (10/3) is installed again.

5. Thread the cutting line outwards through

opening (10/6) of the spool head.

6. Fit cover (10/5) and press on until it engages.

7. Install the rechargeable battery in the appli-

ance.

Bring the cutting line to the required length
(13).

1. Switch on the appliance.

2. Tap (13/a) spool head (13/1) on the lawn

from time to time. This unwinds a piece of
new cutting line from the spool.

3. Switch off the appliance and wait until the

cutter head has come to a standstill.

4. Check the line length.

5. Repeat the previous steps until the cutting

line has the required length.

9

STORAGE

Thoroughly clean the appliance after each use
and – if present – attach all covers. Store the ap-
pliance in a dry, lockable place out of the reach of
children.

■

Hang up the lawn trimmer by its handle. This
avoids placing unnecessary load on the cut-
ter head.

Carry out the following jobs before intervals in
work lasting for longer than 30 days:

■

Thoroughly clean the appliance and store it in
a dry place.

9.1

Storage of battery and charger

DANGER!
Danger of explosion and
fire!

Persons will be fatally or
severely injured if the re-
chargeable battery ex-
plodes because it was
stored in front of naked
flames or heat sources.

■

Store the rechargeable
battery in cool and dry
conditions, but not in
front of naked flames or
heat sources.

NOTE

When charging, the rechargeable bat-
tery is protected from overcharging due
to automatic detection of the charge
status and thus can remain connected to
the charging unit for some time, but not
permanently.

■

Store the rechargeable battery in a dry, frost-
free place at an ambient temperature
between 0°C and 35°C and with a charge
state of approx. 40 - 60%.

■

Do not store the rechargeable battery in the
vicinity of metallic objects or of objects con-
taining acid to avoid the risk of short-circuit.

■

Recharge the rechargeable battery for ap-
prox. 2 hours after approx. 6 months’ stor-
age.

10 TRANSPORT

NOTE

The nominal energy of the rechargeable
battery is more than 100 Wh. Therefore,
observe the following transport instruc-
tions.
