 | English

1 609 92A 0NC | (19.5.14)

Bosch Power Tools

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for drilling in wood, metal, ceramic
and plastic.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Tool holder

2

Opening for drift

3

Gear selector

4

Thread for auxiliary handle

5

Auxiliary handle (insulated gripping surface)

6

Lock-on button for On/Off switch

7

On/Off switch

8

Handle (insulated gripping surface)

9

Drift

10

Reducing sleeve *

11

Tapered arbor *

12

Key chuck *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-1.

Typically the A-weighted noise levels of the product are:
Sound pressure level 86 dB(A); Sound power level 97 dB(A).
Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:
Drilling into metal: a

h

= 3.0 m/s

2

, K < 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, 2014/30/EU,
2006/42/EC including their amendments and complies with
the following standards: EN 60745-1, EN 60745-2-1.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Rotary drill

GBM 32-4

Article number

0 601 130 2..

Rated power input

W

1 500

Output power

W

1 000

No-load speed

– 1st  gear
– 2nd  gear
– 3rd  gear
– 4th  gear

min

-1

min

-1

min

-1

min

-1

210
330
470
740

Rotational speed under load

– 1st  gear
– 2nd  gear
– 3rd  gear
– 4th  gear

min

-1

min

-1

min

-1

min

-1

120
185
265
420

Rated  torque  (1. / 2. / 3. / 4. gear)

Nm 80 / 52 / 36 / 23

The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.

Max. drilling dia.

– Steel
– Wood
– Aluminium

mm
mm
mm

32
70
50

Tool holder

MK 3 – DIN 228

Weight according to
EPTA-Procedure 01/2003

kg

7.3

Protection class

/

II

Rotary drill

GBM 32-4

The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
