B450 Pro4 R2.0

9

English

Storage

•

4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and Hot Plug*

•

2 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061, sup-
port NCQ, AHCI and Hot Plug

* M2_2, SATA3_3 and SATA3_4 share lanes. If either one of
them is in use, the others will be disabled.

•

1 x Ultra M.2 Socket (M2_1), supports M Key type
2242/2260/2280 M.2 PCI Express module up to Gen3 x4 (32
Gb/s) (with Matisse, Picasso, Summit Ridge, Raven Ridge
and Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with Athlon series
APU)**

•

1 x M.2 Socket (M2_2), supports M Key type
2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and
M.2 PCI Express module up to Gen3 x2 (16 Gb/s) **

** If M2_1 is occupied, PCIE4 will be disabled.
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit

Connector

•

1 x COM Port Header

•

1 x TPM Header

•

1 x Power LED and Speaker Header

•

1 x RGB LED Header

* Supports in total up to 12V/3A, 36W LED Strip

•

1 x Addressable LED Header

* Supports in total up to 5V/3A, 15W LED Strip

•

1 x AMD Fan LED Header

*The AMD Fan LED Header supports LED strips of maximum
load of 3A (36W) and length up to 2.5M.

•

1 x CPU Fan Connector (4-pin)

* The CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.

•

1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)

* The CPU/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.

•

3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)
