Adjustable fence

15

Bevel lock lever

16

Laser beam outlet

17

Roller

18

Saw blade

19

Dust bag

20

Laser on/off switch (for marking of cutting line)

21

On/Off switch

22

Chip ejector

23

Mounting holes for material clamp

24

Hex key

25

Tilt-protector bar

26

Transport safety-lock

27

Material clamp

28

Spindle lock

29

Indicator for bevel angle

30

Scale for bevel angle

31

Fastening screw for insert plate

32

Fastening screw for tilt-protector bar

33

Hex socket screw for mounting of saw blade

34

Clamping flange

35

Interior clamping flange

36

Wing bolt

37

Threaded rod

38

Clamping lever of the adjustable fence

Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.

Technical Data

Noise Information

Sound emission values determined according to
EN 61029-2-9.

Typically the A-weighted noise levels of the product are:
Sound pressure level 96 dB(A); Sound power level
103 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, until
19 April 2016: 2004/108/EC, from 20 April 2016 on:
2014/30/EU, 2006/42/EC including their amendments and
complies with the following standards:
EN 61029-1, EN 61029-2-9, EN 60825-1.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 23.06.2015

Assembly



Avoid unintentional starting of the machine. During as-
sembly and for all work on the machine, the power plug
must not be connected to the mains supply.

Delivery Scope

Please also observe the representation of
the delivery scope at the beginning of the op-
erating instructions.

Before starting the operation of the machine
for the first time, check if all parts listed be-

low have been supplied:

– Mitre saw with mounted saw blade
– Dust  bag

19

– Material  clamp

27

– Hex  key

24

– Tilt-protector bar

25

 with fastening screws

32

Note:

Check the power tool for possible damage.

Before further use of the machine, check that all protective
devices are fully functional. Any lightly damaged parts must
be carefully checked to ensure flawless operation of the tool.
All parts must be properly mounted and all conditions fulfilled
that ensure faultless operation.
Damaged protective devices and parts must be immediately
replaced by an authorised service centre.

Mitre Saw

PCM 8

Article number

3 603 M10 0..

Rated power input

W

1200

No-load speed

min

-1

4800

Laser type

nm

mW

650

< 1

Laser class

2

Weight according to
EPTA-Procedure 01:2014

kg

7.9

Protection class

/

II

Permissible workpiece dimensions (maximum/minimum) see page 24.

The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.

Dimension of suitable saw blades

Saw blade diameter

mm

216

Blade body thickness

mm

1.4 – 1.8

Max. cutting width

mm

2

Mounting hole diameter

mm

30
