2.  ANGLE TRANSMISSION (Fig. 16)

Lubricate with lithium-based grease.

Remove the screw (1) and put in the grease, turn

-

ing the shaft manually until grease emerges, then

replace the screw (1).

3.  3-POINT BLADE

The cutting edges of a 3-point blade do not require

sharpening.

3 point blades can be used from both sides.

When one side of the points is worn, the blade

can be turned and the other side used.

WARNING!

  The blade must never be

repaired, but must be replaced as soon as

signs of breaking are noted.

4.  HEAD COIL REPLACEMENT (Fig. 17)

–   Follow the sequence indicated in the figure.

5.   SHARPENING THE LINE CUTTING KNIFE

(Fig. 18)

–   Remove the line cutting knife (1) from the guard

(2) by unscrewing the screws (3).

WARNING!

  For your safety and that of

others:
–  After each use, disconnect the machine

from the mains and check for damage.

–  Correct maintenance is essential to main­

tain the original efficiency and safety of the

machine over time.

–   Keep all nuts, bolts and screws tight to be

sure the equipment is in safe working con­

dition.

–   Never use the machine with worn or dam­

aged parts. Damaged parts are to be re­

placed and never repaired.

–   Only use original spare parts. Parts that are

not of the same quality can seriously dam­

age the equipment and compromise safety.

WARNING!

 During maintenance op­

erations unplug the machine from the mains.

1.  MOTOR COOLING

To  avoid  overheating  and  damage  to  the  motor,

always  keep  the  cooling  air  vents  clean  and  free

of sawdust and debris.

4.   END OF OPERATIONS

–   Switch off the engine as indicated above (Chap.

6).

–   Wait  for  the  cutting  device  to  stop  and  fit  the

blade guard.

WARNING!

  Allow the motor to cool

before storing in any enclosure.

To  reduce  fire  hazards,  clean  the  machine

thoroughly to get rid of any remains of grass,

leaves or excess grease, never leave contain­

ers with the cut debris inside the storage area.

Remember that the nylon line could lop or damage

small shrubs and that the impact of the nylon line

against the trunk of bushes or trees with soft bark

could seriously damage the plant.
•

Adjusting line length when working

(Fig. 15)

This machine is fitted with a “Tap & Go” head.

To release more line, tap the cutting line head

against the round with the engine at top speed:

the line will be released automatically and the knife

cut off the excess length.

26

USING THE MACHINE / MAINTENANCE AND STORAGE/

EN

  8.  MAINTENANCE AND STORAGE
