Pull off the screwing-depth stop

4

 toward the front. Pull out

the screwdriver bit

1

. If required, the universal bit holder

13

can also be pulled off and replaced.

After changing the tool, reattach the screwing-depth stop

4

.

Operation

Starting Operation

Inserting the battery



Use only original Bosch lithium-ion batteries with the
voltage listed on the nameplate of your power tool.

Using other batteries can lead to injuries and pose a fire
hazard.

Note:

Use of batteries not suitable for the machine can lead to

malfunctions of or cause damage to the power tool.

Set the rotational direction switch

5

 to the centre position in

order to avoid unintentional starting. Insert the charged bat-
tery

9

 into the handle so that it can be felt to engage and faces

flush against the handle.

Reversing the rotational direction

The rotational direction switch

5

 is used to reverse the rota-

tional direction of the machine. However, this is not possible
with the On/Off switch

7

 actuated.

Rotate clockwise:

Move the rotational direction switch

5

on both sides up to the stop into position

.

Rotate anticlockwise:

Move the rotational direction

switch

5

 on both sides up to the stop into position

.

Switching On and Off

To

start

 the machine, press the On/Off switch

7

 and keep it

pressed.

The LED

12

 lights up when the On/Off switch

7

 is halfway or

fully pressed, and enables illumination of the screwing loca-
tion in unfavourable light conditions.

To

lock

 the pressed On/Off switch

7

, press the lock-on button

6

.

To

switch off

 the machine, release the On/Off switch

7

 or

when it is locked with the lock-on button

6

, briefly press the

On/Off switch

7

 and then release it.

To save energy, only switch the power tool on when using it.

Adjusting the Speed

The speed of the switched-on power tool can be variably ad-
justed, depending on how far the On/Off switch

7

 is pressed.

Light pressure on the On/Off switch

7

 results in a low rotation-

al speed. Further pressure on the switch results in an increase
in speed.

Adjusting the Screw-in Depth (see figure B)

With the adjustment sleeve

3

, the screw-in depth of the screw

head into the workpiece can be preset in 8 locking steps per
full turn. Each step corresponds with a 0,25 mm change of
the screw-in depth.

Turning the adjustment sleeve

3

 in clockwise direction results

in a greater screw-in depth; turning in anticlockwise direction
reduces the screw-in depth.

The required setting is best determined by testing.

Temperature Dependent Overload Protection

When using as intended for, the power tool cannot be subject
to overload. When the load is too high or the allowable battery
temperature range is exceeded, the speed is reduced. The
power tool will not run at full speed until reaching the allow-
able battery temperature.

Protection Against Deep Discharging

The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.

Working Advice



Apply the power tool to the screw only when it is
switched off.

Rotating tool inserts can slip off.

Guide the screw toward the screwdriving bit

1

. The screw is

held in place by the magnet pull of the universal bit holder

13

.

Firmly push the tip of the screw into the material to be
screwed until the screwing-depth stop

4

 faces against the

workpiece.

Switch the machine on. The screw is screwed into the materi-
al until the adjusted screw-in depth is reached. The drive is
disengaged and the tool holder no longer rotates. Check the
screw-in depth and readjust, if required.

For unscrewing screws, set the rotational direction switch

5

to left rotation and pull off the screwing-depth stop

4

 toward

the front without turning the adjustment sleeve.
Working with the screwing-depth stop

4

 is also possible when

adapting the screw-in depth.

Belt Clip

With the belt clip

8

, the machine can be hung onto a belt. The

user has both hands free and the machine is always at hand.

Maintenance and Service

Maintenance and Cleaning



Before any work on the machine itself (e. g. mainte-
nance, tool change, etc.) as well as during transport
and storage, remove the battery from the power tool.

There is danger of injury when unintentionally actuating
the On/Off switch.



For safe and proper working, always keep the machine
and ventilation slots clean.

When the battery is no longer operative, please refer to an au-
thorised after-sales service agent for Bosch power tools.

After-sales Service and Application Service

Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:

www.bosch-pt.com

Bosch’s application service team will gladly answer questions
concerning our products and their accessories.
