Fit the wet casing on the sausage filler nozzle.

●

Make  sure  the  not  to  block  the  ventilation  openings  on  the

nozzle.

The  meat  cannot  be  „too  thin”.  A  large  liquid  content  may

cause its leakage to the inside of the mincer.

Citrus juicer

(Fig. 6)

The citrus juicer is an additional appliance, which enables to

squeeze juice from citrus fruits together with the pulp.
Citrus juicer unit:

  I.  Clutch

  II.  Bowl

  III.  Screen

  IV.  Squeezer

Open the lid of the compartment on the back of the housing,

which enables to operate the appliance in a vertical position.

Place the appliance on a hard, even surface.
Fit the following elements onto the motor:

Clutch.

●

Fix the bowl to the motor and turn left until you hear a click.

●

It means that the bowl has been properly installed.

Attach  the  screen  and  the  squeezer  to  the  protruding  part

●

of the bowl.

Prepare the fruits by cutting them into halves.

●

Plug in the appliance.

●

Switch  on  the  appliance  using  the

●

„I”

switch  and

place  the  fruit  on  the  squeezer  with  the  pulp  facing  the

squeezer.

Push to start the squeezing process.

●

CAUTION!  In  case  the  sieve  is  blocked  with  the  pulp

of  extracted  fruit,  it  is  necessary  to  switch  off  the

appliance, disassemble the sieve and empty it, as the

excess  of  the  pulp  can  cause  leakage  to  the  motor

chamber of the appliance.

CAUTION!  The  citrus  juicer  spins  during  operation.

Pay special attention to your fingers while pushing the

fruits on the squeezer.

Shredder

(Fig. 7)

  I.  Fine grating disc

  II.  Coarse grating disc

  III.  Slicing disc

  IV.  Pureeing disc

  V.  Locking tab

  VI.  Body

 VII.  Tray

 VIII.  Pusher
The  shredder  is  equipped  with  two  grating  discs  for  fine

(I)

  and  coarse

(II)

  grates  (cheese,  carrot,  celery,  cooked

beetroots  etc.).  The  slicing  disc

  (III)

  is  used  to  slice

vegetables  (potatoes,  cucumbers,  onions,  etc.).  The  purée

disc

(IV)

is used to purée potatoes, beetroots, fruits, etc.

In order to prepare the shredder for operation:

Pull  the  locking  tab

●

  (V)

and  place  one  of  the  discs  with

the clutch facing the inside of the body.

Snap the tab shut.

●

Assemble  the  shredder  body  in  the  same  way  as  the

●

mincer body.

Cut larger products into pieces.

●

Do not grind soft fruits with hard stones.

●

Switch off and unplug the appliance after operation.

●

Remove  the  remaining  products  from  the  inside  of  the

●

disc or body using a wooden spoon.

The blades of the discs do to require renovation.

Replacing the discs (Fig. 8).

Juicer

(Fig. 9)

The  juice  squeezer  is  an  equipment  included  to  some

types of mincers. It allows to squeeze juice from fruits such

as:  raspberries,  currants,  strawberries,  gooseberry  and

additionally  from  grapes  and  tomatoes.  Berry  fruits  such

as  currants  can  be  squeezed  with  stalks.  Fruits  with  large

stones for example plums, cherries etc can be squeezed in

the appliance after removing the stones.
Appliance elements:

  I.  Chamber

  II.  Worm

  III.  Body

  IV.  Nut

  V.  Juice channel

  VI.  Adjusting screw

 VII.  Bowl (from the mincing unit)

 VIII.  Pusher (from the mincing unit)

  IX.  Screen – 2 pieces

    No. 1 – smaller openings

    No. 2 – larger openings

  X.  Large sealing ring for the body

(3)

  XI.  Small sealing ring for the worm

(2)

NOTE: Use only the pusher to push fruits (8).

Preparing for operation and operation

Make  sure  the  sealing  rings

●

(10)

  and

(11)

  are  installed

on  the  body

(3)

  and  worm

(2)

.  If  not,  please  install  the

sealing rings in the openings of these elements (the body

and the worm).

Insert  the  screen

●

(9)

  into  the  body

(3)

  and  push  until

stop.

Insert the worm

●

(2)

 into the squeezer chamber

(1)

 and insert

the  body  with  the  screen  onto  the  worm  paying  attention

that  the  sieve  is  placed  downwards,  and  the  positioning

opening fits the protrusion of the squeezer chamber.

Screw the nut

●

(4)

 onto the squeezer chamber

(1)

.

Screw  the  adjustment  screw

●

(6)

  into  the  body

(3)

  and

insert the juice channel

(5)

 until it snaps shut on the body

(3)

 and you hear a click.
