20

 | English

Line Laser

GLL 3‑80 C

GLL 3-80 CG

Permitted ambient temperature during
operation

–10 °C to +40 °C

–10 °C to +40 °C

Permitted ambient temperature during
storage

–20 °C to +70 °C

–20 °C to +70 °C

Recommended rechargeable batteries

GBA 12V…

(except for GBA 12V ≥ 4.0 Ah)

GBA 12V…

(except for GBA 12V ≥ 4.0 Ah)

Recommended chargers

GAL 12…

GAX 18…

GAL 12…

GAX 18…

A) The working range may be reduced by unfavourable environmental conditions (e.g. direct sunlight).
B) At

20–25

 °C

C) Applies to the four horizontal intersection points
D) The values stated presuppose normal to favourable environmental conditions (e.g. no vibration, no fog, no smoke, no direct sunlight). Ex-

treme fluctuations in temperature can cause deviations in accuracy.

E) Only non-conductive deposits occur, whereby occasional temporary conductivity caused by condensation is expected.
F) Shorter operating times in

Bluetooth

® operation and/or in conjunction with RM 3

G) When using

Bluetooth®

 Low Energy devices, it may not be possible to establish a connection depending on the model and operating system.

Bluetooth®

 devices must support the SPP profile.

H) The signal range may vary greatly depending on external conditions, including the receiving device used. The

Bluetooth®

 range may be signi-

ficantly weaker inside closed rooms and through metallic barriers (e.g. walls, shelving units, cases, etc.).

I)

The lithium-ion battery and the AA1 battery adapter are excluded from IP 54.

The serial number

(18)

 on the type plate is used to clearly identify your measuring tool.

Assembly

Measuring Tool Power Supply

The measuring tool can be operated either with conventional
non-rechargeable batteries or with a Bosch lithium-ion bat-
tery.

Operation with Rechargeable Battery

u

Use only the chargers listed in the technical data.

 Only

these chargers are matched to the lithium-ion battery of
your measuring tool.

Note:

Lithium-ion rechargeable batteries are supplied par-

tially charged according to international transport regula-
tions. To ensure full rechargeable battery capacity, fully
charge the rechargeable battery before using your tool for
the first time.
To

insert

 the charged battery

(15)

, slide it into the battery

bay

(10)

 until you feel it engage.

To

remove

 the battery

(15)

, press the release buttons

(13)

and pull it out of the battery bay

(10)

.

Do not use force to

do this.

Operation with Non-Rechargeable Batteries

It is recommended that you use alkaline manganese batter-
ies to operate the measuring tool.
The batteries are inserted into the battery adapter.

u

The battery adapter is intended only for use in desig-
nated Bosch measuring tools and must not be used
with power tools.

To

insert

 the batteries, slide the cover

(11)

 of the battery

adapter into the battery bay

(10)

. Place the batteries into

the cover as per the illustration on the sealing cap

(14)

.

Slide the sealing cap over the cover until you feel it click into
place.

To

remove

 the batteries

(12)

, press the re-

lease buttons

(13)

 of the sealing cap

(14)

 and

pull off the sealing cap. Make sure that the bat-
teries do not fall out. To do this, hold the meas-
uring tool with the battery bay

(10)

 facing up-

ward. Remove the batteries. To remove the
cover

(11)

 from inside the battery bay, reach

into the cover and pull it out of the measuring

tool, applying light pressure to the side wall as you do so.
Always replace all the batteries at the same time. Only use
batteries from the same manufacturer and which have the
same capacity.

u

Take the batteries out of the measuring tool when you
are not using it for a prolonged period of time.

 The bat-

teries can corrode and self-discharge during prolonged
storage in the measuring tool.

Battery Charge Indicator

The battery charge indicator

(2)

 shows the state of charge of

the battery/batteries:

LED

State of charge

Green continuous light

100–75 %

Yellow continuous light

75–35 %

Red continuous light

35–10 %

No light

– Rechargeable battery de-

fective

– Batteries drained

If the rechargeable battery or non-rechargeable batteries are
running low, the laser lines will gradually become dimmer.
