18

 | English

work on the measuring tool (e.g. assembly, mainten-
ance, etc.). The battery/batteries should also be re-
moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.

u

When operating the measuring tool, loud signal tones
may sound under certain circumstances. For this
reason, keep the measuring tool away from your ears
and from other persons.

 The loud sound can damage

hearing.

Keep the measuring tool and the magnetic
accessories away from implants and other
medical devices, e.g. pacemakers or insulin
pumps.

 The magnets inside the measuring tool

and accessories generate a field that can impair
the function of implants and medical devices.

u

Keep the measuring tool and the magnetic accessor-
ies away from magnetic data storage media and mag-
netically sensitive devices.

 The effect of the magnets in-

side the measuring tool and accessories can lead to irre-
versible data loss.

u

The measuring tool is equipped with a wireless inter-
face. Local operating restrictions, e.g. in aeroplanes
or hospitals, must be observed.

The

Bluetooth

®

word mark and logos are registered trade-

marks owned by Bluetooth SIG, Inc. and any use of such
marks by Robert Bosch Power Tools GmbH is under li-
cense.

u

Caution! When using the measuring tool with

Bluetooth

®

, a fault may occur in other devices and sys-

tems, aeroplanes and medical devices (e.g. pace-
makers, hearing aids). Also, damage to people and an-
imals in the immediate vicinity cannot be completely
excluded. Do not use the measuring tool with

Bluetooth

®

in the vicinity of medical devices, petrol

stations, chemical plants, areas with a potentially ex-
plosive atmosphere and in blasting areas. Do not use
the measuring tool with

Bluetooth

®

on aeroplanes.

Avoid using the product near your body for extended
periods.

Product Description and
Specifications

Please observe the illustrations at the beginning of this oper-
ating manual.

Intended Use

The measuring tool is intended for determining and checking
horizontal and vertical lines.
The measuring tool is suitable for indoor and outdoor use.

Product Features

The numbering of the product features shown refers to the il-
lustration of the measuring tool on the graphic page.

(1)

Laser beam outlet aperture

(2)

State of charge of rechargeable batteries/non-re-
chargeable batteries

(3)

Display

CAL guard

(4)

Pendulum lock indicator

(5)

Receiver mode button

(6)

Receiver mode indicator

(7)

Button for laser operating mode

(8)

Bluetooth

® connection indicator

(9)

Bluetooth

® button

(10)

Battery bay

(11)

Battery adapter cover

a)

(12)

Batteries

a)

(13)

Rechargeable battery/battery adapter release but-
ton

a)

(14)

Battery adapter cap

a)

(15)

Rechargeable battery

a)

(16)

On/off switch

(17)

Laser warning label

(18)

Serial number

(19)

5/8" tripod mount

(20)

1/4" tripod mount

(21)

Coin cell

(22)

Coin cell holder

(23)

Coin cell port

(24)

Magnet

a)

(25)

Universal holder

a)

(26)

Rotating platform

a)

(27)

Remote control

a)

(28)

Laser target plate

a)

(29)

Laser receiver

a)

(30)

Laser viewing glasses

a)

(31)

Protective bag

a)

(32)

Tripod

a)

(33)

Telescopic rod

a)

(34)

Case

a)

(35)

Inlay

a)

a)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical Data

Line Laser

GLL 3‑80 C

GLL 3-80 CG

Article number

3 601 K63 R..

 3 601 K63 T..
