GB

Original instructions for use

24

Petrol Generator INVERTER 2000i

(green) (

15/3)

is not lit anymore. Power generation is

interrupted, the engine continues running.
1.  Switch off all connected electric devices.
2.  Switch off the engine
3.  Reduce the total power of the connected electric

devices within the rated output power

4.  Check ventilation grille and operating panel for

contamination and clean if necessary

5.  Restart the engine after the check

If electric devices requiring a high starting current

(such as a compressor or submersible pump) are

used, the overload indicator lamp can light up for

a few seconds. However, this is not a malfunc-

tion.

AC indicator lamp (green)

(

15/3

)

The AC indicator lamp lights up if the engine is running

and power is generated.

DC safety switch

(

16

)

The DC safety switch switches automatically to “OFF”

(

16/2

), if electric consumers are connected to the

generator and the electrical power is greater than the

operating current.

Switch on the DC safety switch again by pressing the

“ON” button (

16/1

) in order to use the machine again.

Important!

If the DC safety switch switches to "OFF", reduce

the total power of all connected consumers to

the maximum rated power (DC) of the generator.

Please contact the AL-KO service centre if the

DC safety switch permanently switches to "OFF".

ESC (Engine Smart Control)

(

8

)

“ON”

If the ESC switch is switched to “ON”, the Economy

control unit controls the engine speed depending on the

power of the connected electric devices. This results in

lower fuel consumption and less noise.

“OFF”

If the ESC switch is switched to “OFF”, the engine runs at

nominal speed (5000 rpm) regardless of any connected

electric devices.

The ESC switch must be set to "OFF" if electric

devices with high starting current (such as a com-

pressor or submersible pump) are connected.

Connecting power consumers to AC

Important!

The total power of all connected consumers must

not exceed the maximum rated power of the

generator

1.  Check whether the AC indicator lamp is lit
2.  Plug consumer into the socket of the generator

If several consumers are connected to the gen-

erator, connect and switch on the first consumer

(consumer with highest power) first. Then con

-

nect and switch on further consumers.

Disconnecting power consumers

1.  Disconnect consumer from the socket of the

generator

Connecting a 12-Volt (car) battery for charging

Important – Danger of explosion!

Do not mix up the charging cables during battery

connection

Important

Observe the information of the battery manufac-

turer regarding battery charging

2.  Start the engine
3.  Connect the battery charging cable to the DC

connection (12 V)

4.  Connect the red charging cable with the positive

battery terminal

5.  Connect the black charging cable with the negative

battery terminal

6.  Switch the ESC switch to “OFF” to start charging

Switching the engine off

Only switch the generator off, after it has been

running for 30 seconds without any load (without

consumers connected)
