 English |

15

Bosch Power Tools

1 609 92A 11C | (12.11.14)

25

Wing bolt for angle adjustment

26

Scale for routing angle adjustment

27

Handle of the guide plate *

28

Extraction hood *

29

Extraction adapter *

30

Side-handle subbase *

31

Nut for adjustment of the tensioning force

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-17.

Typically the A-weighted noise levels of the product are:
Sound pressure level 84 dB(A); Sound power level 95 dB(A).
Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:
a

h

= 4.5 m/s

2

, K = 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, 2014/30/EU,
2006/42/EC including their amendments and complies with
the following standards: EN 60745-1, EN 60745-2-17.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 01.10.2014

Assembly

Changing the Tool



Before any work on the machine itself, pull the mains
plug.



It is recommended to wear protective gloves when in-
serting or replacing router bits.

Disassembling the Routing Base (see figure A)

Before a router bit can be inserted, the routing base

2

 must

first be removed from the motor unit

1

.

– Open the clamping lever

10

 and turn the routing base

2

 so

that the

 mark is in line with the

 symbol on the mo-

tor unit

1

.

– Pull the motor unit upward to the stop.
– Turn the motor unit in anticlockwise direction to the stop

and pull it out of the routing base.

Replacing the Collet (see figure B)

Depending on the routing tool being used, the tightening nut
with the collet

5

 may need to be replaced before inserting the

router bit.
When the right collet for your router bit is already mounted,
follow the work steps as described under “Inserting a Router
Bit”.

Laminate trimmer

GKF 600

GKF 600

Article number

3 601 F0A 1..

3 601 F0A 16.
3 601 F0A 17.

Rated power input

W

600

600

No-load speed

min

-1

33000

33000

Tool holder

mm

inch

6 / 8

–

–

¼

Weight according to EPTA-Procedure 01/2003

kg

1.5

1.5

Protection class

/

II

/

II

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9
