Technical Data
Noise Information
Measured sound values determined according to EN 61029.
Typically the A-weighted noise levels of the product are:
Sound pressure level 98 dB(A); Sound power level
111 dB(A). Uncertainty K = 3 dB.
Wear hearing protection!
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 61029
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.
EC Type Certification No. MSR 1035 by notified testing agen-
cy No. 0366.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, Dept. PT/ETM9,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 30.08.2011
Assembly
f
Avoid unintentional starting of the machine. During as-
sembly and for all work on the machine, the power plug
must not be connected to the mains supply.
Delivery Scope
Please also observe the representation of the
delivery scope at the beginning of the operat-
ing instructions.
Before starting the operation of the machine
for the first time, check if all parts listed below
have been supplied:
– Table saw with mounted saw blade
32
and riving knife
7
– Angle stop
3
– Profile rail
34
– Fastening kit “profile rail”
52
(guide plate, knurled nut,
screw, washer)
– Parallel guide
8
– Auxiliary parallel guide
49
– “Auxiliary parallel guide” fastening kit
39
(3 fastening
screws, 3 washers, 3 wing nuts)
– Blade guard
5.x
*
* depending on country version:
5.1
/
5.2
– Table extension
10
– Fastening kit for “table extension”
43
(2 fastening screws, 2 washers, 1 open-end spanner)
– Allen key
37
– Ring spanner
15
– Cover of the saw blade storage
14
– Push stick
13
– Insert plate
31
Table saw
GTS 10 XC Professional
Article number
3 601 L30 400
3 601 L30 440
3 601 L30 470
3 601 L30 490
3 601 L30 4P0
3 601 L30 4R0
3 601 L30 460
3 601 L30 430
Rated power input
W
2100
1650
2000
No-load speed
min
-1
3200
4200
4200
Reduced starting current
z
z
z
Run-on Brake
z
z
z
Overload Protection
z
z
z
Weight according to EPTA-Procedure 01/2003
kg
35
35
35
Protection class
/
II
/
II
/
II
Dimensions (incl. removable product features)
Width x depth x height
mm 775 x 768 x 343 775 x 768 x 343 775 x 768 x 343
Maximum workpiece dimensions, see page 38.
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
Dimension of suitable saw blades
Saw blade diameter
mm
254
Blade body thickness
mm
1.8
Tooth thickness/setting, min.
mm
2.6
Mounting hole diameter
mm
30
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Engineering Director
PT/ESI
