Creating Discs with a DVD Writer or

External Blu-ray Drive

While a DVD writer is used in the following explanation, the same operations apply for an external

Blu-ray drive.

1

Connect the USB cable and the AC

adapter.

0

Turn off the camcorder by pressing the

M

button for about 2 seconds.

A

Connect the USB cable provided with

the DVD writer.

B

Connect the AC adapter of the DVD

writer.

C

Connect the AC adapter to this unit.

0

This unit powers on automatically when

the AC adapter is connected.

.

AC Adapter
To AC Outlet
(110 V

㨪

240 V)

To DC Connector

To USB
Connector

DVD Writer
(CU-VD3)

0

Refer also to the instruction manual of

the DVD writer or external Blu-ray drive.

0

This unit turns on and the “BACK-UP”

menu appears.

0

While the USB cable is connected, the

“BACK-UP” menu is displayed.

2

Turn on the DVD writer or external Blu-

ray drive and insert a new disc.

o

To play back the created disc

Play back on an AVCHD compatible device

(such as Blu-ray recorder).

o

Compatible DVD writers

0

CU-VD50

0

CU-VD3

o

Compatible external Blu-ray drive

0

You can use BE08LU20 from LG.

0

To use the USB cable provided with the

external Blu-ray drive, purchase the USB

extension cable.

* Mini-A (Male) – A (Female)

(Part number: QAM0852-001)

Consult your nearest JVC service center.

NOTE

0

The recordable time on the disc

varies according to the way of

recording.

0

When connected to this unit, all

buttons on the DVD writer (CU-

VD50), other than the power and

eject buttons, will not work.

0

It is recommended to format your

DVD-RW on a computer before

using.

For more information, refer to the Detailed User Guide

http://manual.jvc.co.jp/index.html/
