11

 En

Connections

English

INTR

ODUCTION

AD

DITIONAL

INFORMA

T

ION

APPENDIX

PRE

P

ARA

T

ION

BA

S

IC

OPERA

T

ION

AD

V

ANCED

OPERA

T

ION

Audio jacks and cable plugs

AUDIO jacks

For conventional analog audio signals transmitted via left
and right analog audio cables. Connect red plugs to the
right jacks and white plugs to the left jacks.

COAXIAL jack

For digital audio signals transmitted via coaxial digital
audio cable.

OPTICAL jacks

For digital audio signals transmitted via optical digital
audio cables.

Notes

•

You can use the digital jacks to input PCM, Dolby Digital, and DTS
bitstreams. All digital input jacks are compatible with digital signals with
up to 96 kHz of sampling frequency.

•

This unit handles digital and analog signals independently. Thus audio
signals input at the digital jacks are not output at the analog AUDIO OUT
(REC) jack.

Video jacks and cable plugs

VIDEO jacks

For conventional composite video signals transmitted via
composite video cables.

COMPONENT VIDEO jacks

For component signals, separated into the luminance (Y)
and chrominance (P

B

, P

R

) video signals transmitted on

separate wires of component video cables.

You can play back pictures by connecting your video
monitor and video source component to this unit using
HDMI connections.
At that time, audio/video signals output from the
connected component (such as DVD player etc.) are
output to the connected video monitor only when this unit
is turned on and set to the input source (DVD or DTV/
CBL).
Furthermore, available audio/video signals depend on the
specification of the connected video monitor. Refer to the
instruction manual of each connected component.

■

HDMI jack and cable plug

y

•

We recommend using an HDMI cable shorter than 5 meters (16 feet)
with the HDMI logo printed on it.

•

Use a conversion cable (HDMI jack

↔

 DVI-D jack) to connect this unit

to other DVI components.

You can record the audio signal output at the AUDIO
OUT (REC) jack by using the recording components.

Note

•

Check the copyright laws in your country to record from CDs, radio, etc.
Recording of copyrighted material may infringe copyright laws.

Connecting video components

Information on jacks and cable plugs

 COAXIAL

 DI

G

ITAL AUDIO

AUDIO

 OPTICAL

 DI

G

ITAL AUDIO

R

L

C

O

R

L

(White)

(Red)

(Orange)

Left and right

analog audio

cable plugs

Coaxial

digital audio

cable plug

Optical

digital

audio cable

plug

 VIDEO

COMPONENT VIDEO

Y

P

B

P

R

P

B

Y

P

R

V

(Yellow)

(Blue)

(Red)

(Green)

Composite

video cable

plug

Component

video cable

plugs

Information on HDMI™

Audio signals input at the HDMI jack are not output
from any speaker terminals but output from the
connected video monitor. To enjoy the sound from
speakers connected to this unit,

–

make an analog or digital connection besides the
HDMI connection (see page 13).

–

mute the volume of the connected video monitor.

Using the AUDIO OUT REC jack

P

R

P

B

Y

P

R

P

B

Y

COMPONENT
VIDEO

VIDEO

Video signal flow for MONITOR OUT

Input

Output

(MONITOR OUT)

HDMI

HDMI cable plug
