35

KNOWING YOUR SEWING MACHINE

KENNENLERNEN IHRER MASCHINE

КРАТКОЕ ТЕХНИЧЕСКОЕ ОПИСАНИЕ МАШИНЫ

(Model STAR 240E, STAR 230E)
4. Slide the sewing speed controller to its maximum (as far to the

right as possible).

5. Push the Start/Stop button. The machine will stop automatically

when the bobbin is full.

6. After the bobbin has stopped moving, push the Start/Stop button

to stop the machine.

1

Sewing speed controller

CAUTION
When removing the bobbin, do not pull on the bobbin winder
seat. Doing so could loosen or remove the bobbin winder seat,
resulting in damage to the machine.

7. Cut the thread, slide the bobbin winder shaft to the left and

remove the bobbin.

(Mode PS-57, PS-55, STAR-50, RSR-55, XRX-55, PS-53)
4. Step down on the foot controller to start.
5. After the machine stops automatically when the bobbin is full,

take your foot off of the foot controller.

CAUTION
When removing the bobbin, do not pull on the bobbin winder
seat. Doing so could loosen or remove the bobbin winder seat,
resulting in damage to the machine.

6. Cut the thread, slide the bobbin winder shaft to the left and

remove the bobbin.

NOTE:
The needle bar does not  move when the bobbin winding shaft is slid
to the right.
Immediately after winding the bobbin, it is normal to hear the sound
of the clutch engaging when beginning to sew or manually turning
the balance wheel.

CAUTION

Be sure to follow the process described. If the thread is not
cut completely, and the bobbin is wound, when the thread
runs low it may tangle around the bobbin and cause the
needle to break.

CAUTION

Setting the bobbin improperly may cause the thread ten-
sion to loosen, breaking the needle and resulting in injury.

1

Wound evenly

2

Wound poorly

1

2

(Model STAR 240E, STAR 230E)

(Model PS-57, PS-55, STAR-50, RSR-55, XRX-55, PS-53)

1
