Dreame W10 - Инструкция по эксплуатации - Страница 8

12

13

EN

EN

Fast Mapping

How to Use

Remove the mop pad before fast mapping.

After you connect the robot to the app, create a map as instructed in the app.

The robot moves around to scan the environment and creates a map without

cleaning. After the robot returns to the base, a map is created and saved

automatically.

Pause / Sleep

When the robot is cleaning, press briefly any buttons on the robot or the

button on the base to pause the robot.

If the robot pauses for more than 10 minutes, it automatically enters the sleep

mode, and the power indicator and charging indicator stop glowing. Press

any buttons on the robot or base, or tap on the app to wake up the robot.

Note:

· The robot will turn off automatically if it is left in the sleep mode for more than 12 hours.

· If the robot is paused and placed onto the base, the current cleaning process will end.

Restoring Factory Settings

If the robot does not function properly and the buttons do not respond after

being restarted, use a pin to press the reset button for 3 seconds until you

hear a voice saying "Restoring factory settings". It will take about 5 minutes

to reset the robot to its original factory settings. After resetting the robot, you

must recreate maps and no-go zones.

Turn On/Off

When the robot is not placed on the base and is on standby, press briefly

the      button to enable the spot cleaning mode. In this mode, the robot cleans a

square-shaped area of 1.5 × 1.5 meters around it and returns to its starting point

once the spot cleaning is completed.

Spot Cleaning

Press and hold the   button for 3 seconds to turn on the robot, and the power

indicator is permanently on. Place the robot onto the base, and the robot

turns on automatically and starts charging. To turn off the robot, move the

robot away from the base, and press and hold the   button for 3 seconds.

1.5 m

1.5 m

Note:

· Make sure that the robot is fully charged before using it. Do not manually move

  the robot when it is cleaning.

· If the battery gets low while cleaning, the robot returns to the base and resumes

  cleaning after charging its battery.（The Resume Cleaning function must be enabled

  on the app in advance.）

Cleaning Mode

After the robot is turned on, it cleans each room by cleaning along the

edges and walls first and then cleaning in an S-shaped pattern. The robot

automatically returns to the base to charge its battery after cleaning.

How to Use

Sweeping Function

Note:

 Do not attach the mop pad while using the sweeping function.

Method 1: Press briefly the      button on the base, and the robot starts

sweeping.

Method 2: Press briefly the      button on the robot, and the robot starts sweeping.

MAX

To the MAX Line

Mopping Function

1. Attach the mop pad

2. Take out the fresh tank, fill it with clean water, and then place the fresh

tank into the base.

Note:

· Do not fill in hot water, otherwise the fresh tank may be deformed.

· Use only the Dreame-brand multi-surface floor cleaner. Otherwise, the functions

   of the base may be affected.

Note:

Do not use the mopping function on the carpet.
