12

 | English

F 016 L70 995 | (10.6.13)

Bosch Power Tools

Starting

For Your Safety

Warning! Switch off, remove plug from mains

before adjusting, cleaning or if cable is cut,

damaged or entangled.

The operating voltage is 230 V AC, 50 Hz (for non-EU coun-

tries 220 V, 240 V as applicable). Only use approved exten-

sion cables. Contact your Bosch Service Centre for details.
If you want to use an extension cable when operating your

high pressure washer, only the following cable dimensions

should be used:
- 1.5 mm

2

 – max length 20 m

- 2.5 mm

2

 – max length 50 m

Note: If an extension cable is used it must be earthed and con-

nected through the plug to the earth cable of your supply net-

work in accordance with prescribed safety regulations.
If in doubt contact a qualified electrician or the nearest Bosch

Service Centre.

WARNING! Inadequate extension cables can

be dangerous. Extension cable, plug and sock-

et must be of watertight construction and in-

tended for outdoor use.

Cable connections should be kept dry and off the ground.
For increased electrical safety to use a Residual Current De-

vice (RCD) with a tripping current of not more than 30 mA. Al-

ways check your RCD every time you use it.
If the supply cord is damaged, it must be replaced by a Bosch

Service Centre.
For products

not sold in GB

:

WARNING:

 For your safety, it is required that the plug at-

tached to the machine is connected with the extension cord.

The coupling of the extension cord must be protected against

splash water, be made of rubber or coated with rubber. The

extension cord must be used with a cable strain relief.

Products sold in GB only

: Your product is fitted with an

BS 1363/A approved electric plug with internal fuse (ASTA

approved to BS 1362).

If the plug is not suitable for your socket outlets, it should be

cut off and an appropriate plug fitted in its place by an author-

ised customer service agent. The replacement plug should

have the same fuse rating as the original plug.

The severed plug must be disposed of to avoid a possible

shock hazard and should never be inserted into a mains sock-

et elsewhere.
To prevent damage to the appliance, do not allow it to operate

dry.

Operation

Starting

Attach water supply hose (not supplied) to the mains water

supply and machine.
Connect the product to the mains supply ensuring that the

mains switch is in the off position.
Open water tap.
Press the safety lock (back button on the gun handle) to re-

lease the trigger. Fully press the trigger until there is a con-

stant flow of water to clear the air from the machine and water

supply hose. Release trigger. Press the safety lock (front but-

ton on the gun handle).
Turn button on main switch. Point the power gun downwards.

Press the trigger safety lock to release the trigger. Fully press

the trigger.

Autostop function

The machine is designed to switch off the motor when the trig-

ger is released on the gun.

Working Advice

General

Ensure that the pressure washer is on level ground.
Do not overreach with the high pressure hose or move the

pressure washer by pulling the hose, this could cause the ma-

chine to become unstable and fall over.
Do not kink or drive a motor vehicle over the high pressure

hose. Do not expose the high pressure hose to sharp edges or

corners.
Never use a roto nozzle to clean motor vehicles.

WARNING!

The Patio Cleaners supplied are only intended to

be used on flat surfaces! Do not attempt to use them on steps

or vertical surfaces. Never attempt to touch the rotating noz-

zle while operating the machine!

Working advice for cleaning with detergents



Only use cleaning agents suitable specifically for high

pressure washers.

We recommend that you use detergent sparingly for the sake

of the environment. Observe the recommended dilution on

the detergent label.

Recommended cleaning method

Step 1: Loosening dirt

Select the foam setting on the 3 in 1 nozzle and spray on the

detergent sparingly.

Step 2: Removing dirt

Spray off the loosened dirt with the high-pressure spray.

Note:

When cleaning a vertical surface spray off dirt/deter-

gent from the bottom and work in an upwards direction. Rinse

from the top and work downwards.

Clean the water filter

10

Clean nozzle

11

Gun storage

12

Gun/lance/nozzle is stored in action

13

Hose into the hose holder

14

Storage

15

Selecting Accessories

16

Action

Figure
