18

Continued from previous column

Fan Connectors

∙

1x 4-pin CPU fan connector

∙

1x 4-pin water-pump fan connector

∙

3x 4-pin system fan connectors

System Connectors

∙

1x Front panel audio connector

∙

2x System panel connectors

∙

1x Chassis intrusion connector

∙

1x TPM module connector

∙

1x Tuning controller connector

Jumpers

∙

1x Clear CMOS jumper

∙

1x OC safe boot jumper

LED Features

∙

2x 4-pin RGB LED connectors

∙

2x 3-pin A-RAINBOW V2 (ARGB Gen2) LED connectors

∙

4x EZ Debug LED

Back Panel

Connectors

∙

1x Flash BIOS button

∙

1x DisplayPort

∙

1x HDMI™ port

∙

4x USB 3.2 Gen 1 5Gbps Type-A ports (From ASM1074)

∙

3x USB 3.2 Gen 2 10Gbps Type-A ports (From CPU)

∙

1x USB 3.2 Gen 2x2 20Gbps Type-C port (From B650

chipset)

∙

1x 2.5Gbps LAN (RJ45) port

∙

2x Wi-Fi antenna connectors

∙

5x audio jacks

∙

1x Optical S/PDIF Out connector

I/O Controller

NUVOTON NCT6687R Controller Chip

Hardware Monitor

∙

CPU/ System/ Chipset temperature detection

∙

CPU/ System/ Pump fan speed detection

∙

CPU/ System/ Pump fan speed control

Form Factor

∙

Micro-ATX Form Factor

∙

9.6 in. x 9.6 in. (244 mm x 244 mm)

Continued on next column
