English

25

X570 Steel Legend

Please note that only one cable should be used at a time in this step.
If you select

AMD_FAN_LED1

, please install ASRock utility "ASRock Polychrome SYNC".

If you select USB connector, please install AMD utility "SR3 Settings Software".

*The diagrams shown here are for reference only. The headers might be in a different position on your
motherboard. Please refer to page 35 for the orientation of

AMD Fan LED Header (AMD_FAN_LED1)

and page 31 for the orientation of AMD LED Fan USB Header (USB_5).

2.3  Installing Memory Modules (DIMM)

This motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots,
and supports Dual Channel Memory Technology.

AMD non-XMP Memory Frequency Support

Ryzen Series CPUs (Matisse):

Ryzen Series CPUs (Pinnacle Ridge):

1.  For dual channel configuration, you always need to install identical (the same

brand, speed, size and chip-type) DDR4 DIMM pairs.

2.  It is unable to activate Dual Channel Memory Technology with only one or three

memory module installed.

3.  It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4

slot; otherwise, this motherboard and DIMM may be damaged.

4.  We suggest that you install the memory modules on DDR4_ A2 and DDR4_B2 first

for better DRAM compatibility on 2 DIMMs configuration.

UDIMM Memory Slot

Frequency

(Mhz)

A1

A2

B1

B2

-

SR

-

-

3200

-

DR

-

-

3200

-

SR

-

SR

3200

-

DR

-

DR

3200

SR

SR

SR

SR

2933

SR/DR

DR

SR/DR

DR

2667

SR/DR

SR/DR

SR/DR

SR/DR

2667

UDIMM Memory Slot

Frequency

(Mhz)

A1

A2

B1

B2

-

SR

-

-

2933

-

DR

-

-

2933

-

SR

-

SR

2933

-

DR

-

DR

2933

SR

SR

SR

SR

2933

SR/DR

DR

SR/DR

DR

2667

SR/DR

SR/DR

SR/DR

SR/DR

2133-2400
