13

insert a round rod through the central hole and support
the blade horizontally. A balance blade will remain
horizontal. If the blade is not balanced the heavy end will
rotate downwards. Reshape the heavy end until the blade
is currently balanced. To remove the blade (2), unscrew
the blade screw (3).
Check the conditions of the fan (1), and replace any parts,
which are damaged.
When reassembling, make sure that the cutting edges
face in the direction of the motor rotation. The blade screw
(3) must be tightened to torque 20-25 Nm.

WARNING:

 For service, replace the blade with:

MAKITA 263001461 for ELM4612 and ELM4613 only.

(Fig. 28, Fig. 29, Fig. 30, Fig. 31)

WARNING:

 Disconnect the electric cord from the

power supply.

WARNING:

 Protect hands by using heavy gloves

or a rag to grasp the cutting blades when replace the
blade.

12. EXTENSION CORDS

You should only use extension cords for outdoor use,
ordinary duty with a cross sectional area not less than
1.0 mm

2

.

Before using, check the supply and extension cords for
signs of damage during use, disconnect the cord for signs
of damage or aging. If the cord becomes damaged during
use, disconnect the cord from the supply immediately. DO
NOT TOUCH THE CORD BEFORE DISCONNECTING
THE SUPPLY. Do not use the appliance if the cord is
damaged or worn. Keep extension cord away from cutting
elements.

WARNING:

 Always ensure that the ventilation

openings are kept clear of debris.

13. MAINTENANCE AND CARE

WARNING:

Before performing any maintenance

or cleaning work, always pull out the mains plug!
Do not spray the unit with water. Ingress of water may
destroy the switch-plug combination unit and the electric
motor. Clean the unit with a cloth, hand brush, etc.

Expert inspection is required, do not make any
adjustment by yourself, must contact Makita
authorized service centre:

a) if the lawn mower strikes an object.
b) if the motor stops suddenly.
c) if the blade is bent (do not align!).
d) if the motor shaft is bent (do not align!).
e) if a short-circuit occurs when the cable is connected.
f) If the gears are damaged.
g) If the V-belt is defective.

14. TROUBLESHOOTING

WARNING:

 Before performing any maintenance

or cleaning work, always pull out the mains plug and wait
until the cutter has come to a standstill.

CAUTION:

 Faults which cannot be rectified with

the aid of this table may be rectified by Makita authorized
service centre only.

15. ENVIRONMENTALLY

FRIENDLY DISPOSAL

According to EU directive 2002/96/EC on
electric and electronic equipment and its
implementation into national law, all electric
tools must be separately collected and
environmentally friendly recycled. Alternative
disposal: If the owner of the power tool does

not return the tool to the manufacturer, he is responsible
for proper disposal at a designated collection point that
prepares the device for recycling according to national
recycling laws and regulations.
This does not include accessories and tools without
electric or electronic components.

For European countries only
EC Declaration of Conformity
We Makita Corporation as the responsible
manufacturer declare that the following Makita
machine(s):

Designation of Machine: Lawn Mower
Model No./Type: ELM4612, ELM4613
Specifications: See “4. TECHNICAL DATA” are of series
production and

Conforms to the following European Directives:

2004/108/EC, 2006/42/EC, 2000/14/EC & 2005/88/
EC, 2006/95/EC

Fault

Remedial action

Motor does not
run

Check mains connection cable.
Start on short grass or on an area which
has already been mown.
Clean discharge channel/housing-the
mowing blade must rotate freely.
Correct the cutting height.

Motor power
drops

Correct the cutting height.
Clean discharge channel/housing.
Have mowing blade resharpened/
replaced



authorized service centre.

Grass catcher
is not filled

Correct the cutting height.
Allow the lawn to dry.
Have mowing blade resharpened/
replaced



authorized service centre.

Clean the grille on the grass catcher.
Clean the discharge channel/housing.

Wheel drive
does not
function

Adjust the flexible cable.
Check the V-belt/gears



authorized

service centre.
Check the drive wheels for damage.
