11

4. TECHNICAL DATA

5. ASSEMBLY

5-1 ASSEMBLE THE FOLDING HANDLE

1. Fix the lower handlebar onto the handle bracket with

bolt, washer and locking knob.

(Fig. 3)

2. Lift the two locking levers to connect the upper and

lower handle.

(Fig. 4)

3. Push the locking lever closed to lock the handlebars in

the operating position.

(Fig. 5)

4. Adjust the tension by turning the lock nut with a

suitable spanner.

(Fig. 6)

5. Position the cable over the handle shaft. Clamp it

around the middle of lower handle by the cable clamp
and make sure the cable is fixed around the outside of
the handle.

(Fig. 7)

 Otherwise the cable may be

pinched by opening/closing the rear cover.

5-2 ASSEMBLE THE GRASS CATCHER

1. To fit: Raise the rear cover and hitch the grass catcher

on rear of mower.

(Fig. 8, Fig. 9, Fig. 10)

2. To remove: Grasp and lift the rear cover, remove

grass catcher.

GRASS CATCHER

There is a level indicator on the top of the grass catcher
that shows whether the catcher is empty or full

(Fig. 11,

Fig. 12)

:

- The level indicator inflates if the catcher is not full during

the moving.

(Fig. 12)

- If the catcher is full, the indicator collapses. Once this

happens, stop moving immediately and empty the
catcher, make sure it is clean and ensure its meshwork
is ventilated.

(Fig. 11)

IMPORTANT

If the position of indicator opening is very dirty, the
indicator will not inflate. In this case, clean the position of
indicator opening immediately.

6. ADJUSTMENT OF CUTTING

HEIGHT

Apply outward pressure to disengage lever from rack.
Move lever forward or back to adjust height.
The height (the blade to the ground) can be adjusted from
20 mm (the lowest position) to 75 mm (the highest
position), 8 height positions.

(Fig. 13)

WARNING:

 Make this adjustment only when the

blade is stopped.

WARNING:

 Disconnect the electric cord from the

power supply.

7. ADJUSTMENT FOR AN

APPROPRIATE ANGLE

a) Pull the locking lever opening.
b) Rotating the upper handle centered of the angle

adjusting gear for adjusting an appropriate angle into
the scope -15º to 15º (3 position: -15º/0º/15º) as the

Fig. 14

 shown.

c) Push the locking lever closed to connect the lower

handle and the upper handle.

8. FUNCTION

These lawn mowers can be retrofitted from its normal
function, based on the application purpose.
From lawn mower with rear collection to:
Mulching mower or as
Side-discharge mower.
What is mulching?
When mulching, the grass is cut in one working step, then
finely chopped and returned to the grass strip as natural
fertilizer.

Model:

ELM4612

ELM4613

Rated voltage:

230 V~

230 V~

Rated frequency:

50 Hz

50 Hz

Rated power:

1,800 W

1,800 W

No load speed:

2,900/min

2,900/min

Cutting width:

460 mm

460 mm

Grass catcher capacity:

60 L

60 L

Net weight:

29.5 kg

32.5 kg

Degree of protection against liquid:

IPX4

IPX4

Height adjustment:

20-75 mm, 8 adjustment

20-75 mm, 8 adjustment

ELM4612

ELM4613

Sound pressure level at operator’s
position

78.9 dB (A)  K=3 dB (A)

78.9 dB (A)  K=3 dB (A)

Measured sound power level

91.6 dB (A)  K=1.94 dB (A)

91.6 dB (A)  K=1.94 dB (A)

Guaranteed sound power level

96 dB (A)

96 dB (A)

Vibration 1.132

m/s

2

 K=1.5 m/s

2

1.132 m/s

2

 K=1.5 m/s

2
