128
EN
Setting the end of cooking time
The oven must switch off after the set end time.
Before setting the end of cooking time you have to
set the
oven operating function
and the
temperature
(see chapter
“Cooking”
)
•
Touch the key
1
two times to get the
lighting symbol
2
.
The display
3
shows the current time. The blinking
separatory colon informs that the end of cooking
time can be setted.
•
By using the choise keys
4
you set the
desired end of cooking time
5
.
After setting the cooking duration the display
3
shows the actual time. After a few seconds it
comes a sound signal and the countdown of the
cooking duration starts.
•
To find out the end of cooking time during
the cooking, touch the key
1
.
•
By using the choice keys
4
you can set the
wanted duration during the cooking. At first
you should toch the key
1
.
After the end of the cooking time the oven emits
beeping sounds (which increase its loudness)
during three minutes. On display blinks preseted
duration of cooking time.
•
Touch any key to stop the bipping sounds
and blinking indication on display.
Important!
By setting a cooking end time
earlier than the current time the oven will
begin to cook from now until the time set on
the following day!
1
2
4
3
5
Important!
If you don’t choose an oven
funktion within 8 seconds after the buzzer
silenced, the oven is turned off
automatically.
