To Resume Recording

Press the

REC

button again.

➥

Recording will resume at the point of interruption.

■

Recording from external Microphone or other

Devices

The external microphone and other devices can be connected
and the sound can be recorded.

• When the external microphone is connected to the microphone jack

of the recorder, the built-in microphone will not operate.

• When using an external microphone, choose adequate microphone,

such as a Noise-Cancellation microphone or Electret condenser

microphone (optional).

• When connecting an external equipment, use the connecting cord

KA333 (optional).

Q

A audio input terminal of other devices

(Fig.

{

)

Notes for Recording

• If “FULL” appears on the display, you cannot record in the selected

 folder. In such a case, erase unnecessary files or download to PC

(VN-1100PC/VN-2100PC/VN-3100PC/VN-4100PC).

• If the recorder is placed directly on a table when recording a meeting,

it tends to pick up table vibrations. Put a notebook or other item

between the table and the recorder so that the vibration is not easily

transmitted for clearer recording.

• Even if you press the DISPLAY button, the display will not change to

current recording time if the remaining recording time is 5 minutes

or less.

• When remaining recording time falls to 1 minute or less, the

Record/Play indicator light flashes red.

• The recorder will enter Stop mode if it has been left paused for

60 minutes or longer.

• In case of difficult acoustic conditions or low speaker’s voice,

recording in XHQ or HQ is recommended. Also, usage of an external

microphone (sold separately) could improve the quality of recordings.

• The input level cannot be adjusted on this recorder. When you

 connect the recorder to an external device, execute a test recording

and adjust the output level of the external device.

■

LCD Display Information

You can select an option for the display of the recorder. This help
review and confirm different recorder settings and file information.

Playing Back

(Fig.

}

)

1.

Press the

FOLDER

button to select the desired folder.

2.

Press the

9

or

0

button to select the file to play back.

3.

Press the

PLAY

button to start playback. The Record/Play

indicator light turns green, and the elapsed playing time is
indicated on the display.

4.

Press the

+

or

–

button to select the proper sound volume.

The display shows the volume level. You can choose between
0 to 30.

Q

Current folder,

W

Current file number,

E

Playing time

■

Canceling Playback (Fig.

≠

)

To Stop

Press the

STOP

button.

➥

The recorder stops in the middle of the file being played.

To Resume Playback

Press the

PLAY

button again.

➥

Playback will resume at the point of interruption.

■

Forwarding and Rewinding (Fig.

«

)

Fast Forward

Press and hold the

9

button while playing a file.

➥

When you release the

9

button, the recorder will resume

normal playback.

Rewind

Press and hold the

0

button while playing a file.

➥

When you release the

0

button, the recorder will resume

normal playback.

• The end of the file is located by pressing and holding the

9

 button during fast forwarding. The recorder will pause at the end

of the file.

If you do not release the

9

button, the recorder will continue fast

forward.

• The beginning of the file is located by pressing and holding the

0

button during rewinding. The recorder will pause at the beginning of

the file. If you do not release the

0

button, the recorder will

continue rewinding.

• When the index mark is shown in the middle of a file, it will stop

temporarily in the position of the index mark.

■

Changing Playing Speed (Fig.

∑

)

You can change the playing speed by pressing the PLAY button while
the recorder is playing back.

• When the slow playback mode is selected, the “SLOW” appears and,

for the fast playback mode, “FAST” appears on the display while the

recorder is playing back.

• The recorder stops playing when you press the STOP button while

playing back in the slow/fast mode, or when it reaches to the end of

the file. If you once press the STOP button and start playback again,

the recorder will play back files in normal speed as well.

■

Locating the Beginning of the File

While the recorder is playing back or playing back in slow/fast
mode, pressing the

9

or

0

button forwards or rewinds to the

beginning of the next file or the file being played respectively.
If an index mark is encountered midway, playback begins at that
point. (See “Index Marks” for details)

■

Listening with Earphones (Fig.

™

)

You can listen to files by connecting earphones to the earphone jack.
If an earphone is connected, the speaker doesn’t emit sound. Sound
will be played back monaurally.

• To avoid irritation to the ear, insert the earphone after turn down the

volume level.

• When you listen with the earphone during playback, do not raise the

volume too much. It may cause hearing impairment and decrease in

hearing ability.

* Earphones are not supplied. You can use any standard 3.5mm

monaural earphone or headphone.

Normal speed

Slow playback

(–25%)

Fast playback

(+50%)

7

EN

State of the

recorder

Operation

Display

While in stop

mode

Press and hold

the

STOP

button

The total number of files recorded in

the folder and remaining recording time

appears on the display.

While in record

mode

Press the

DISPLAY

button

The display switches between current

recording time and remaining recording

time.

While in stop

mode or

playback mode

Press the

DISPLAY

button

Playing time

➞

Remaining playing time

➞

Recording date of the file

➞

Recording

time of the file

➞

Playing time …
