Sparky MBGS 200 - Инструкция по эксплуатации - Страница 5

3

Original instructions

EN

II -

Technical specifications

Dust from material such as paint containing lead, some wood species, minerals and metal may be harmful. Contact
with or inhalation of the dust may cause allergic reactions and/or respiratory diseases to the operator or bystanders.

Certain kinds of dust are classified as carcinogenic such as oak and beech dust especially in conjunction with additives

for wood conditioning (chromate, wood preservative). Material containing asbestos must only be treated by specialists.

▪

Where the use of a dust extraction device is possible it shall be used.

▪

The work place must be well ventilated.

▪

The use of a dust mask of filter class P2 is recommended.

Follow national requirements for the materials you want to work with.

Model:

MBG

150

MBG

175

MBG

200

MBG

250

MBGT

150

MBGS

200

▪

Power input

W

520

520

900

900

520

900

▪

No load speed

min

-1

2950

2950

2950

2950

2950

2950

▪

Wheel diameter

mm

150

175

200

250

150

200

▪

Wheel arbor

mm

32

32

32

32

32

32

▪

Wheel thickness

mm

25

25

32

32

25

32

▪  Brush dimensions

mm

-

-

-

-

Ø150x20xØ32

-

▪  Sanding area

mm

-

-

-

-

-

140x100

▪  Belt dimensions

mm

-

-

-

-

-

914x100

▪

Sound pressure level

dB (A)

82,7

82,7

84,1

84,1

82,7

84,1

▪

Sound power level

dB (A)

95,7

95,7

97,1

97,1

95,7

97,1

▪

Short-time duty S2

min

30

30

30

30

30

30

▪

Protection class

IP 20

IP 20

IP 20

IP 20

IP 20

IP 20

▪

Weight (EPTA

procedure 11/2005)

kg

16.0

18.0

28.0

32.0

15.5

32.0

▪

Safety class

(EN 61029 -1)

I

I

I

I

I

I

III - Safe operation

WARNING!

 When using electric tools basic

safety precautions should always be followed to reduce

the risk of fire, electric shock and personal injury including

the following.

Read all these instructions before attempting to op-

erate this product and save these instructions.

1.   Keep work area clear

  -   Cluttered areas and benches invite injuries.

2.   Consider work area environment

  -   Do not expose tools to rain.

  -   Do not use tools in damp or wet locations.

  -   Keep work area well lit.

  -   Do not use tools in the presence of flammable liq-

uids or gases.

3.   Guard against electric shock

  -   Avoid body contact with earthed or grounded sur-

faces (e.g. pipes, radiators, ranges, refrigerators).

4.   Keep other persons away

  -   Do not let persons, especially children, not involved

in the work touch the tool or the extension cord and

keep them away from the work area.

5.   Store idle tools

  -   When not in use, tools should be stored in a dry

locked-up place, out of reach of children.

6.   Do not force the tool

  -   It will do the job better and safer at the rate for which

it was intended.

7.   Use the right tool

  -   Do not force small tools to do the job of a heavy duty

tool.

  -   Do not use tools for purposes not intended; for ex-

ample do not use circular saws to cut tree limbs or

logs.

8.   Dress properly

  -   Do not wear loose clothing or jewellery; they can be

caught in moving parts.

  -   Non-skid footwear is recommended when working

outdoors.

  -   Wear protective hair covering to contain long hair.

9.  Use protective equipment

  -   Use safety glasses.

  -   Use face or dust mask if working operations create

dust.

10.   Connect dust extraction equipment

  -  If the tool is provided for the connection of dust ex-

traction and collecting equipment, ensure these are

connected and properly used.

11.   Do not abuse the cord
