Instructions for use and maintenance

EN

 •

During the heating the appliance could produce a hissing noise (the

boiling water). This is common and does not indicate any damage.

The noise gets higher with the time and the reason for this is the

accumulation of limestone. To remove the noise the appliance must

be cleaned from limestone. This type of cleaning is not covered by the

warranty.

 •

In order to secure the water heater's safe operation, the safety return-

valve must undergo regular cleaning and inspections for normal

functioning /the valve must not be obstructed/, and for the regions with

highly calcareous water it must be cleaned from the accumulated lime

scale. This service is not provided under warranty maintenance.

 •

All alterations and modifications to the water heater's construction and

electrical circuitry are forbidden.

If such alterations or modifications

are established during inspection, the appliance's warranty shall be

null and void.

КAlterations and modifications shall mean each instances

of removal of elements incorporated by the manufacturer, building in

additional components into the water heater, replacement of elements by

similar elements unapproved by the manufacturer.

 •

If the supply cord (of models that have one) is damaged, it must

be replaced by a representative of the service or by an appropriately

qualified person, in order to avoid any risks

 •

This appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or lack

of experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand

the hazards involved

 •

 Children shall not play with the appliance.

 •

Cleaning and user maintenance shall not be made by children without

supervision.

IV.

DESCRIPTION AND PRINCIPLE OF OPERATION

The appliance consists of a body, flange, plastic control

panel, safety return valve.

1.

The body consists of a steel reservoir (water tank)

and  plastic housing (outer shell) with thermal insulation

placed in-between, and two pipes with thread G ½“, for

cold water supply (marked with a blue ring) and hot water

discharge (marked with a red ring). The inner reservoir is

made of steel proved against corrosion by a special glass-

ceramic coating

2.

The flange is fitted with electric heater and magnesium

anode protector. The flange is fixed to the water tank with

bolts.

The electric heater heats the water in the tank and is

controlled by the thermostat, which automatically maintains

the preset temperature.
The plastic control panel incorporates: switch (depending on

model), adjustable thermostat (depending on model), and

thermal cut-out and control lamps.
The thermal cut-out is a  device, which switches the heater

off the power supply when the water temperature reaches

excessive values. If this device is actuated, you should call a

service station.
The signal lamps (depending on model) on the control panel

indicate the current mode of the unit.
The magnesium protector provides additional anti-corrosion

protection to the internal tank for heaters fitted with glass-

ceramic coating.

3.

The safety-return valve prevents the appliance's

complete emptying in the event of cold water supply

interruption. The valve protects the appliance from

pressure increases higher than the allowed value during

heating (! pressure will increase when temperature

increases), by releasing the excess pressure through the

drain outlet. Water dropping out through the drains

during the warming process is a normal event that must

be taken into consideration when the boiler is installed.

ATTENTION! The safety-return valve cannot protect the

appliance in the event of water mains pressure in

excess of the acceptable pressure stated for the appliance.
