These operating instructions describe the maximum
equipment. Depending on the model, there are differ-
ences in the scopes of delivery (see packaging).



Illustrations on fold-out page!



Illustrations on Page 2

Illustration



Fill the water reservoir up to the "MAX" marking.

Illustration



Insert the steam plug into the appliance connector.

Illustration



Plug in the mains plug.



Switch on the appliance by turning the selector
switch.

Illustration



Display - steam gun lights up green.
Display - steam level lights up white and/or Vapo-
Hydro level lights up red.
Display - heater blinks green.

Once the display (heater) lights up permanently,
the steam cleaner is ready to use.

Illustration



Connect the accessories to the steam gun.



Operate steam lever.



Illustrations on fold-out page!



Illustration
Open the cover of the appliance socket.



Tightly insert the steam plug into the appliance con-
nector. The plug must click into place audibly.

To disconnect:

 Press the cover of the appliance connector down
and disconnect the steam plug from the appliance
connector.



Illustration

 -

Connect the required accessories (see Chapter
"How to use the accessories“) to the steam gun. In-
sert the open end of the accessory on the steam
gun and push onto the steam gun until the unlock-
ing button of the steam gun locks into place.



Illustration
Use the extension tubes if necessary. To do so,
connect one or both extension tubes to the steam
gun. Insert the required accessories on the free
end of the extension tube.



Move the child protection unit toward the back
(steam lever locked).



Illustration
To detach the accessory parts, press the unlocking
button and pull the items apart.

Description of the Appliance

A1

Appliance connector with cover

A2

Water reservoir

A3

Carry handle for water reservoir

A4

Selector switch

A5

Operating panel

a

Display - OFF position

b

Display - water shortage (RED)

c

Display - heater (GREEN)

d

Steam level 1

e

Steam level 2

f

Steam level 3

g

Steam level 4

h

Steam level Vapohydro function

i

Display - iron detection

j

Display - steam gun detection

A6

Locking door for accessories compartment

A7

Maintenance lock

A8

Carrying handle

A9

Holder for accessories

A10 Accessories storage
A11 Storage for mains connection cable
A12 Storage holder for floor nozzle
A13 Mains cable with mains plug
A14 Running wheels (2 ea.)
A15 Steering roller

B1

Steam gun

B2

Steam lever

B3

Unlocking button

B4

Child lock

B5

Steam hose

B6

Steam plug

C1

Detail nozzle

C2

Round brush

Black

C3

Round brush

Red

C4

Power nozzle

red

C5

Round brush

Large

D1

Hand nozzle

D2

Microfibre cloth cover

E1

Extension tubes (two tubes)

E2

Unlocking button

F1

Floor nozzle

F2

Side-flaps

F3

Microfibre floor cloth

2 pieces

G1

Decalcifying sticks

Option

H1

Steam pressure iron

H2

Upper steam button

H3

Display - heater (ORANGE)

H4

Lower steam button

H5

Steam lock

H6

Temperature controller

H7

Steam plug

Quick Reference

Operation

Attaching the Accessories

Removing the Accessories
