23

en

Operation

Note:

If using the kneading hook, rotate the dough 

deflector until the kneading hook can lock 

into position 

(Fig.

E

-4b)

.

■ Put the ingredients to be processed into 

the bowl.

■ Press the Release button and 

move the swivel arm to position 

1

.

■ Attach the cover.

■ Set the rotary switch to the desired setting.

Our recommendation:

–

Stirrer:

first stir in at setting 1 (1), then select 

setting 7 (4)

–

Whisk:

setting 7 (4), mix in at setting 1 (1)

–

Kneading hook:

first stir in at setting 1 (1), knead at 

setting 3 (2)

Adding more ingredients

■ Switch off the appliance with the rotary 

switch.

■ Add more ingredients through the feed 

tube in the cover.

or

■ Remove lid.

■ Press the Release button and 

move the swivel arm to position 

2

.

■ Add ingredients.

After using the appliance

■ Switch off the appliance with the rotary 

switch.

■ Remove mains plug.

■ Remove lid.

■ Press the Release button and 

move the swivel arm to position 

2

.

■ Take the tool out of the drive.

■ Remove the bowl.

■ Clean all parts, see “Cleaning and 

servicing”.

Continuous-feed shredder

W

Risk of injury

Do not grip the sharp blades or edges of the 

cutting discs. Take hold of cutting discs by 

the edge only. Before attaching / removing 

the continuousfeed shredder, wait until the 

drive has come to a standstill and pull out the 

mains plug. Do not reach into the feed tube.

Warning!

The continuous­feed shredder must be 

completely assembled before use. Never 

assemble the continuous­feed shredder on 

the base unit. Operate the continuous­feed 

shredder in the indicated operating position 

only.

Predetermined breaking point

Fig.

F

:

The built­in predetermined breaking point 

protects the drive of the appliance. If an 

overload occurs, the drive shaft of the 

 continuous­feed shredder breaks. However, 

the drive shaft can easily be replaced. A new 

disc holder with drive shaft is available from 

customer service.

Reversible slicing disc –

thick / thin

for slicing fruit and vegetables.
Process at setting 5 (3).
Designation on the reversible slicing disc: 

“1” for the thick slicing side 

“3” for the thin slicing side

Warning!

The reversible slicing disc is not suitable for 

slicing hard cheese, bread, rolls or choco­

late. Slice boiled, waxy potatoes only when 

they are cold.

Reversible shredding disc –

coarse / fine

for shredding vegetables, fruit and cheese, 

except for hard cheese (e.g. Parmesan).
Processing at setting 3 (2) or 4 (3).
Designation on the reversible shredding disc: 

“2” for the coarse shredding side 

“4” for the fine shredding side

Warning!

The reversible shredding disc is not suitable 

for shredding nuts. Shred soft cheese with 

the coarse side only at setting 7 (4).

Grating disc – medium-fine

for grating raw potatoes, hard 

cheese (e.g. Parmesan), cooled chocolate 

and nuts.
Process at setting 7 (4).
